T-Motor F1507 KV2700 Brushless Motor - 3S-6S Cinewhoop

Name: T-Motor F1507 KV2700 Brushless Motor - 3S-6S Cinewhoop
Brand: T-Motor
SKU: DRFC-2734
Price: 2049.00 INR
Availability: OutOfStock

₹2,049.00 (Inclusive of all taxes)

Out of Stock

The T-Motor F1507 KV2700 is a high-performance brushless motor engineered for 3-inch Cinewhoop drones, delivering smooth, cinematic flight control across a 3S to 6S LiPo voltage range.

Features

2700KV rating optimized for 3-inch propellers on Cinewhoop frames.
Supports 3S to 6S LiPo batteries with a peak power handling of 519W.
Lightweight 15.2g design with a 12N14P stator for high torque and efficiency.
2mm shaft diameter compatible with standard Cinewhoop propeller mounts.
Includes all necessary mounting hardware: M2.5 screws, M5 lock nut, washer, and E-clip.

Out of stock

Get Notified When Available

Description

The T-Motor F1507 2700KV motor represents a second-generation design focused on cinematic flight performance. Its compact 18.9mm diameter stator is engineered to deliver torque comparable to larger 20-class motors while minimizing weight, resulting in a superior thrust-to-weight ratio for agile, stable control in tight spaces.

Built with a 12N14P magnetic configuration, the motor provides smooth, quiet operation and high efficiency, with an internal resistance of 131mΩ. This design ensures stable power delivery and excellent thermal management, making it reliable for extended indoor or creative FPV filming sessions where precise throttle response is critical.

Key Features

Optimized for 3-inch Cinewhoop builds requiring smooth, stable footage.
High torque-to-weight ratio enables precise, responsive flight control.
Durable construction with premium bearings for long-term reliability.
Efficient 12N14P stator design minimizes power loss and heat generation.
Wide 3S-6S voltage compatibility offers flexibility for different power setups.
Includes comprehensive mounting kit for straightforward installation.

Applications

3-inch Cinewhoop drones for indoor/outdoor cinematic filming.
Lightweight FPV freestyle builds requiring high torque in a compact form factor.
Digital HD (Walksnail, DJI O3) or analog micro whoop builds on 3S-4S power.
Compact long-range explorers where efficiency and low weight are prioritized.

Technical Specifications

Motor KV	2700 KV
Model	F1507
Motor Type	Brushless Outrunner
Voltage Range	3S to 6S LiPo
Shaft Diameter	2 mm
Max Power	519 W
Stator Configuration	12N14P
Peak Current	22 A
Internal Resistance	131 mΩ
Ideal Current	0.6 A
Motor Diameter	18.9 mm
Weight (with wire)	15.2 g

Frequently Asked Questions

What propeller size is the T-Motor F1507 2700KV motor designed for?

The F1507 2700KV motor is specifically optimized for 3-inch propellers, commonly used on Cinewhoop and micro FPV drone frames. Its high KV and torque profile provide the ideal thrust and responsiveness for this propeller class.

What is the maximum recommended battery voltage for this motor?

This motor is rated for use with 3S to 6S LiPo batteries. Always pair it with a compatible Electronic Speed Controller (ESC) rated for the same voltage range and sufficient current (22A peak) to ensure safe and reliable operation.

What mounting hardware is included with the T-Motor F1507?

The package includes four M2.5 CubePilot socket head cap screws for motor mounting, one M5 self-locking nut for propeller retention, one E-clip, and one washer. This provides all necessary hardware for installation on standard Cinewhoop frames.
