Simonk 30A ESC w/ 3.5mm Banana Connector (Female)
Simonk 30A ESC w/ 3.5mm Banana Connector (Female) - Image 2
Simonk 30A ESC w/ 3.5mm Banana Connector (Female) - Image 3
SKU: DRFC-0140
📋 GST Invoice Available

Simonk 30A ESC w/ 3.5mm Banana Connector (Female)

₹709.00 (Inclusive of all taxes)
Out of Stock

This ReadyToSky Simonk 30A ESC provides reliable power delivery and motor control for multi-rotor applications. Featuring a 30A continuous current rating, 35A burst, and a 5V/2A linear BEC, it supports 2-4S LiPo batteries for versatile drone builds.

Features

  • 30A continuous current with 35A burst capability
  • Integrated 5V/2A linear BEC for powering flight controllers
  • Optimized Simonk firmware for multi-rotors and disc motors
  • Compatible with 2-4S LiPo batteries for diverse setups
  • Equipped with 3.5mm banana connectors for easy integration

Out of stock

Description

The ReadyToSky Simonk 30A ESC is engineered specifically for multi-rotor aircraft, providing faster and more precise motor speed control crucial for stable flight performance. It effectively isolates the high-power battery and motor circuit from the sensitive receiver signal side through an optocoupler, ensuring clean signal transmission.

This ESC incorporates a multi-integrated special program that delivers rapid throttle response, outperforming many open-source alternatives. Its firmware is finely tuned for disc motors, offering excellent compatibility across various drone platforms. Built with ultra-low resistance MOSFETs and a dedicated driver integrated circuit, it offers strong current capacity and superior stability compared to designs utilizing discrete components, making it a dependable choice for drone builders.

Key Features

  • Utilizes a multi-integrated circuit with a special program for fast throttle response, surpassing open-source software.
  • Firmware specifically optimized for disc motors, ensuring excellent compatibility with multi-rotor systems.
  • Highly intelligent with strong adaptive capacity, featuring adjustable timing settings (height/middle) for ease of use.
  • Throttle signal line uses twisted wire to minimize crosstalk, enhancing signal stability for more reliable flight.
  • Supports throttle signal refresh rates up to 621Hz, compatible with a wide range of flight controllers.
  • Incorporates a MOSFET special driver integrated circuit for superior performance and stability.
  • Features ultra-low resistance MOSFETs, providing robust current flow capacity for demanding applications.

Applications

  • FPV quadcopters and multi-rotors
  • Beginner and intermediate drone builds
  • General purpose UAV platforms requiring reliable motor control
  • RC aircraft and educational drone projects

Technical Specifications

Item TypeElectronic Speed Controller
Constant Current (A)30A
Burst Current (A)35A
Weight (g)23g
Overall Dimension6 x 3 x 1mm
BEC Output5V/2A Linear
LiPo Cells Supported2-4S
Connector Size3.5mm

Frequently Asked Questions

What are the main power specifications of this ESC?

This ESC features a 30A continuous current rating with a burst capability of 35A. It supports 2-4S LiPo batteries for versatile power configurations and includes a 5V/2A linear BEC to power flight controllers or other accessories. Its design ensures reliable power delivery for various drone applications.

What type of firmware does this ESC use and for what applications is it optimized?

The ReadyToSky 30A ESC utilizes Simonk firmware, specifically optimized for disc motors commonly found in multi-rotors and quadcopters. This optimization ensures fast throttle response and excellent compatibility, contributing to improved flight performance and stability in drone builds.

How does this ESC contribute to stable flight performance?

This ESC enhances flight stability through features like a twisted throttle signal line, which reduces crosstalk for cleaner signal transmission. It also supports refresh rates up to 621Hz, ensuring compatibility with various flight controllers and delivering precise, responsive motor control crucial for agile and stable drone maneuvers.

Package Includes

  • 1 x ReadyToSky Simonk 30A ESC with 3.5mm Banana Connector (Female)

Additional Information

Dimensions 0.6 × 0.3 × 0.1 cm
