Sensirion SHT30-DIS-F2.5KS Humidity & Temperature Sensor ±3%RH, I2C, 2.5kpcs
The Sensirion SHT30-DIS-F2.5KS is a fully calibrated, digital I2C humidity and temperature sensor offering high accuracy (±3% RH, ±0.3°C) across a wide -40°C to 125°C operating range. With a 2.15V to 5.5V supply, it is directly compatible with 3.3V and 5V microcontrollers like Arduino, Raspberry Pi, ESP32, and STM32 for precision environmental monitoring.
Features
- High-Accuracy Sensing: Delivers ±3% relative humidity and ±0.3°C temperature accuracy for reliable data.
- Wide Voltage & Temperature Range: Operates from 2.15V to 5.5V and across an industrial temperature span of -40°C to 125°C.
- Fast Digital I2C Interface: Features a 1 MHz max I2C bus with two user-selectable addresses for easy system integration.
- Ultra-Low Power Design: Consumes only ~600 µA during measurement and 0.2 µA in idle mode for battery-powered applications.
- Factory Calibrated & Stable: Provides fully calibrated, linearized digital output with excellent long-term stability and NIST traceability.
Out of stock
The SHT30-DIS-F2.5KS from Sensirion is a next-generation digital humidity and temperature sensor based on proven CMOSens® technology. It combines a capacitive polymer sensing element for humidity with a band-gap temperature sensor, delivering fully calibrated and temperature-compensated digital signals via a fast I2C interface. The sensor’s robust design ensures high signal integrity and resistance to environmental contaminants.
Engineered for demanding applications, it features a wide supply voltage range, ultra-low power consumption, and optional ALERT and RESET functionality for advanced system control. Housed in a compact 8-pin DFN package, it is designed for high-volume integration into HVAC systems, weather stations, industrial process control, and portable instrumentation where precision and reliability are critical.
Additional Information
| Weight | 0.004 kg |
|---|---|
| Dimensions | 0.4 × 0.4 × 0.09 cm |
