Renke SHT-68 Hard Cover Temperature & Humidity Sensor Probe (SHT20, I²C), 68mm Length

Name: Renke SHT-68 Hard Cover Temperature &amp; Humidity Sensor Probe (SHT20, I²C), 68mm Length
Brand: Renke
SKU: SENS-3809
Price: 779.00 INR
Availability: OutOfStock

₹779.00 (Inclusive of all taxes)

Out of Stock

The Renke SHT-68 is a hard-cased environmental probe integrating a Sensirion SHT20 sensor for precise temperature and humidity measurement. It provides a calibrated digital I2C output, compatible with 3.3V microcontrollers like ESP32, STM32, and Raspberry Pi, making it ideal for industrial and IoT monitoring systems.

Features

Integrates Sensirion SHT20 CMOSens® sensor for high-accuracy readings
Digital I2C interface provides calibrated, linearized output signals
Extended operating temperature range from -40°C to +125°C
Hard protective cover ensures durability in industrial environments
Low power consumption (2.1V-3.6V) suitable for battery-powered nodes

Out of stock

Get Notified When Available

Description

The Renke SHT-68 probe utilizes Sensirion’s SHT20 chip, a CMOSens® technology-based sensor that combines a capacitive humidity sensor and a band-gap temperature sensor on a single silicon die. This integration ensures excellent long-term stability and minimal cross-sensitivity. The sensor is factory-calibrated, delivering linearized digital signals via the I2C bus, which simplifies integration and eliminates the need for user calibration.

Housed in a robust hard cover with a 68mm probe length, this sensor is designed for reliable performance in demanding conditions. Its low power consumption and wide operating voltage range make it a prime choice for embedded environmental monitoring systems, HVAC control, and data-logging applications where space and energy efficiency are critical.

Key Features

Core sensing element based on Sensirion's proven SHT20 CMOSens® technology
Factory-calibrated digital output ensures measurement accuracy and simplifies setup
I2C digital communication interface for direct microcontroller connection
Hard protective casing provides mechanical strength and environmental protection
Wide operating temperature range (-40°C to +125°C) for versatile application use
Optimized for low power consumption, ideal for portable and IoT devices
High long-term stability with minimal signal drift over time
Compact DFN sensor package within a durable 68mm probe form factor

Applications

HVAC system performance monitoring and climate control
Industrial process monitoring for temperature and humidity-sensitive environments
Embedded environmental data loggers for agricultural and weather stations
IoT smart home devices for indoor air quality assessment
Laboratory equipment and scientific instrumentation requiring stable sensing

Technical Specifications

Probe Length	68 mm
Sensor Model	SHT20
Measured Parameters	Temperature & Relative Humidity
Output Interface	Digital (I2C)
Operating Voltage	2.1V to 3.6V DC
Temperature Range	-40°C to +125°C
Temperature Accuracy (Typical)	±0.3°C
Temperature Resolution	Up to 14-bit
Temperature Repeatability	±0.1°C
Shipping Weight	0.074 kg
Shipping Dimensions	15 × 14 × 4 cm

Frequently Asked Questions

What is the operating voltage range for the Renke SHT-68 probe?

The probe operates from 2.1V to 3.6V DC. It is designed for 3.3V logic systems and is not 5V tolerant. A level shifter or voltage divider must be used if connecting to a 5V microcontroller to prevent damage to the Sensirion SHT20 sensor chip.

How do I connect and read data from this sensor using I2C?

The sensor uses a standard I2C interface. Connect the SDA and SCL lines to your microcontroller with appropriate pull-up resistors (typically 4.7kΩ). The default I2C address for the SHT20 is 0x40. You can use existing SHT20/SHT21 libraries for Arduino, ESP32, or Raspberry Pi to request temperature and humidity measurements.

Is the sensor calibrated, and what is its accuracy?

Yes, the Sensirion SHT20 sensor is fully factory-calibrated. It provides a typical temperature accuracy of ±0.3°C and humidity accuracy as per the SHT20 datasheet specifications. The digital output is linearized, so no user calibration is required for most applications.

What is the purpose of the hard cover on the probe?

The hard protective cover provides mechanical durability and shields the internal DFN-packaged sensor from physical impact, dust, and minor moisture splashes. It extends the sensor's lifespan in industrial or outdoor environments, though it is not a substitute for a sealed IP-rated enclosure if full waterproofing is needed.
