Raspberry Pi VGA666 Dtoverlays Module

₹719.00 (Inclusive of all taxes)
Out of Stock

The VGA666 Dtoverlays Module enables Raspberry Pi A+/B+/2B/3B/Zero to output 1080p60 VGA video without consuming CPU resources. This passive adapter allows simultaneous VGA and HDMI display output, making it ideal for connecting legacy monitors.

Features

  • Capable of displaying 1080p60 VGA video with zero CPU load.
  • Supports simultaneous VGA and HDMI display output.
  • Achieves a maximum resolution of 1920×1024.
  • Directly compatible with Raspberry Pi A+/B+/2B/3B/Zero models.
  • Utilizes the DPI interface for efficient digital-to-analog conversion.

Out of stock

Description

The VGA666 Dtoverlays Module, also known as the Gert-VGA-adapter, provides a cost-effective solution for connecting your Raspberry Pi to VGA-only monitors. Unlike traditional digital-to-analog HDMI-to-VGA converters that can be expensive and power-hungry, this passive adapter leverages the Raspberry Pi’s DPI (Display Parallel Interface) to deliver native VGA output.

This module supports video resolutions from 640×480 up to 1920×1024 at 60fps, offering 262,144 colors (6 bits per channel). A key advantage is its ability to drive a VGA display independently, and potentially simultaneously with the HDMI output (with ongoing software development). However, users should note that the VGA666 module utilizes a significant number of GPIO pins, which will limit their availability for other peripherals.

Key Features

  • Directly connects Raspberry Pi 3B / 2B / B+ / A+ / Zero to VGA monitors.
  • Outputs video resolutions from 640x480 up to 1920x1024 at 60fps.
  • Provides 6 bits per color channel, supporting 262,144 distinct colors.
  • Utilizes the Raspberry Pi's DPI interface for efficient video conversion.
  • Operates passively, eliminating the need for external power supplies.
  • Enables dual-screen setups with VGA and HDMI (software dependent).
  • Easy configuration via boot/config.txt file edits.

Applications

  • Integrating legacy VGA monitors with Raspberry Pi setups.
  • Educational and testing environments requiring simple display solutions.
  • Cost-effective display solutions where HDMI is not available or desired.
  • Projects requiring a second display alongside HDMI on Raspberry Pi.

Technical Specifications

Item TypeOther Board
Board TypeVGA Module
Model No. / NameVGA666
Supported Raspberry Pi ModelsA+, B+, 2B, 3B, Zero
Max Video Resolution1920 x 1024
Max Frame Rate (FPS)60 FPS
Color Depth6 bits per channel (262,144 colors)
InterfaceRaspberry Pi GPIO (DPI)

Frequently Asked Questions

Which Raspberry Pi models are compatible with the VGA666 module?

The VGA666 Dtoverlays Module is compatible with Raspberry Pi A+, B+, 2B, 3B, and Zero models. It leverages the DPI interface available on these boards to provide direct VGA output, requiring specific configuration in the /boot/config.txt file for proper operation and resolution settings.

What is the maximum resolution and color depth supported by the VGA666?

The VGA666 module supports a maximum resolution of 1920x1024 at 60 frames per second. It provides 6 bits per color channel, resulting in a color depth of 262,144 distinct colors. This ensures a clear and vibrant display for various applications.

Does the VGA666 module consume CPU resources or draw significant power?

No, the VGA666 module is a passive adapter that utilizes the Raspberry Pi's native DPI interface, allowing it to output 1080p60 VGA video with virtually no CPU load. This design also means it does not require an external power supply, keeping power consumption low.

Can I use the HDMI and VGA outputs simultaneously with this module?

Yes, it is possible to drive the VGA interface at the same time as the HDMI connection, enabling dual-screen setups. However, the software support for optimal dual-screen operation is continually under development, and performance may depend on the specific Raspberry Pi model and GPIO speed.

What are the primary implications of using the VGA666 on my Raspberry Pi's GPIO pins?

The VGA666 module utilizes a significant number of the Raspberry Pi's GPIO pins to establish the DPI interface for VGA output. This means that many GPIO pins will be occupied and unavailable for other peripherals or expansion boards, which is an important consideration for projects requiring extensive GPIO use.

Package Includes

  • 1 x VGA666 Raspberry Pi Dtoverlays Module

Additional Information

Weight 0.01648 kg
Dimensions 6.4 × 3.224 × 2 cm
