MAD Components Components FS 2810 Prius FPV Drone Motor - Red 1180KV
MAD Components Components FS 2810 Prius FPV Drone Motor - Red 1180KV - Image 2
SKU: DRFC-2803
📋 GST Invoice Available

MAD Components Components FS 2810 Prius FPV Drone Motor - Red 1180KV

₹4,889.00 (Inclusive of all taxes)
Out of Stock

The MAD Components Components FS 2810 Prius FPV Drone Motor is a 1180KV brushless motor engineered for 5-6S LiPo long-range and freestyle builds, featuring a lightweight titanium shaft and 0.15mm silicon steel laminations for optimized efficiency and smooth power delivery.

Features

  • 1180KV rating optimized for 5-6S LiPo long-range and freestyle flight.
  • Lightweight titanium shaft and 0.15mm silicon steel stator for improved efficiency.
  • High-precision rotor balance ≤5 mg for exceptionally smooth and stable operation.
  • M5 propeller nut and M3×4 motor mounting holes for secure, versatile installation.
  • Includes 250mm length of durable 18 AWG silicone wire for flexible routing.

Out of stock

Description

The FS 2810 Prius motor from MAD Components Components is engineered for pilots seeking a balance of endurance and responsive freestyle performance. Its 1180KV rating is specifically tuned for 5-6S battery systems, providing the torque and efficiency needed for extended flight times and dynamic maneuvers. The core construction utilizes advanced materials to minimize weight without sacrificing durability.

At its heart, a titanium shaft reduces rotational mass while a stator built from ultra-thin 0.15mm silicon steel laminations minimizes eddy current losses. This combination enhances thermal performance and electrical efficiency. Secondary anodizing provides a durable, visually distinct finish, and the motor’s 12N14P magnetic configuration ensures smooth, cogging-free power delivery across the entire throttle range.

Key Features

  • Optimized KV for High Voltage: 1180KV rating delivers efficient torque and RPM for 5-6S LiPo setups, ideal for long-range cruising and freestyle.
  • Advanced Material Construction: Titanium shaft and 0.15mm silicon steel stator laminations significantly reduce weight and improve electromagnetic efficiency.
  • Precision Dynamic Balance: Rotor assembly balanced to ≤5 mg ensures minimal vibration for smooth video footage and extended bearing life.
  • Robust Mechanical Interface: Features an M5 propeller nut and D:19mm pattern with M3×4 mounting holes for secure attachment to standard frames.
  • Durable Wiring: Comes pre-soldered with a generous 250mm length of flexible, high-strand-count 18 AWG silicone wire.
  • High Pole Count: 12N14P (12 stator slots, 14 magnet poles) design provides smooth rotation and excellent low-RPM throttle control.

Applications

  • 7-inch long-range FPV drones requiring efficient 6S propulsion.
  • Heavy-lift 6-7 inch freestyle and cinematic quadcopters.
  • Endurance-focused fixed-wing or VTOL UAV builds.
  • Custom multirotor projects where a balance of torque and high-voltage efficiency is critical.

Technical Specifications

Motor ModelFS 2810 Prius
BrandMAD Components Components
KV Rating1180 KV
Stator Size28mm x 10mm (2810)
Motor Diameter33.6 mm
Motor Height37.4 mm
Shaft Diameter5 mm
Mounting Hole PatternD: 19mm, M3×4
Propeller MountM5 Nut
Magnetic Configuration12N14P
Wire Gauge & Length18 AWG Silicone, 250 mm
Rotor Balance≤ 5 mg
Recommended Battery5-6S LiPo
ColorRed

Frequently Asked Questions

What size propellers and battery is this 1180KV motor best suited for?

The FS 2810 Prius 1180KV motor is optimized for 5-6S LiPo batteries. It pairs well with larger, high-pitch propellers in the 7-inch range (e.g., 7040, 7050) for efficient long-range flight, or with 6-inch props on 6S for powerful freestyle performance. Always consult motor thrust tables and ensure your Electronic Speed Controllers (ESCs) are rated for the corresponding current draw.

What are the mounting hole dimensions and shaft size?

This motor features a 5mm diameter shaft secured with an included M5 propeller nut. It uses a standard D: 19mm (19mm diameter circle) mounting pattern with four M3 screw holes. The provided M3x4mm screws are for attaching the motor to your frame's arm.

How does the titanium shaft and silicon steel stator benefit performance?

The titanium shaft is significantly lighter and stronger than steel, reducing rotational mass for quicker throttle response. The 0.15mm silicon steel stator laminations minimize eddy current losses, which increases electrical efficiency, reduces heat generation, and improves overall power output, leading to longer flight times and cooler running temperatures.

Package Includes

  • 1 x MAD Components Components FS 2810 Prius FPV Drone Motor (Red, 1180KV)
  • 1 x M5 Propeller Lock Nut
  • Mounting hardware (M3 screws, O-ring, gaskets)

Additional Information

Weight 0.085 kg
Dimensions 5 × 5 × 4 cm
