MAD Components Components FS 2006 MYTHIC FPV Drone Motor 1960KV - Red
MAD Components Components FS 2006 MYTHIC FPV Drone Motor 1960KV - Red - Image 2
MAD Components Components FS 2006 MYTHIC FPV Drone Motor 1960KV - Red - Image 3
SKU: DRFC-2660
📋 GST Invoice Available

MAD Components Components FS 2006 MYTHIC FPV Drone Motor 1960KV - Red

₹2,329.00 (Inclusive of all taxes)
Out of Stock

The MAD Components Components FS 2006 MYTHIC is a 1960KV brushless motor engineered for FPV freestyle drones, featuring a lightweight titanium shaft and high-efficiency silicon steel laminations for optimized performance on 4S-6S LiPo systems.

Features

  • 1960KV rating optimized for 4S-6S LiPo freestyle performance
  • Lightweight titanium shaft for enhanced durability and reduced rotational mass
  • High-efficiency 0.15mm silicon steel stator laminations (80.3mΩ internal resistance)
  • Robust power handling with 23A max current and 537W max power
  • Secondary anodized finish for corrosion resistance and aesthetic appeal

Out of stock

Description

The FS 2006 MYTHIC motor from MAD Components Components represents a dedicated freestyle propulsion solution, developed through six months of intensive flight testing. Its core engineering advancements focus on reducing rotational inertia and electromagnetic losses to deliver responsive throttle control and extended flight times.

Key to its performance is the integration of a precision-machined titanium shaft, which offers superior strength-to-weight ratio compared to standard steel, and ultra-thin 0.15mm silicon steel stator sheets that minimize eddy current losses. This combination results in a motor that efficiently converts electrical input into powerful, smooth thrust across its operating range.

Key Features

  • Freestyle-Optimized Design: Engineered specifically for the dynamic power demands and rapid throttle changes of FPV freestyle flying.
  • Titanium Shaft Construction: Provides significant weight savings and increased shaft strength to withstand impacts and high rotational forces.
  • High-Efficiency Stator: Utilizes 0.15mm silicon steel laminations to reduce core losses and improve thermal performance, evidenced by a low 80.3mΩ internal resistance.
  • High Power Density: Capable of sustaining bursts up to 537W (23A), offering strong acceleration and top-end speed.
  • Durable Anodized Finish: The housing undergoes a secondary anodization process for improved surface hardness, corrosion resistance, and a consistent red color.
  • Precision Balanced Bell: Factory-balanced for smooth operation, reducing vibration and contributing to cleaner video feed and flight controller performance.

Applications

  • 3-inch to 4-inch FPV freestyle quadcopters requiring high torque and rapid throttle response.
  • Lightweight 5-inch freestyle builds where a balance of power and efficiency is critical.
  • Cinematic long-range builds based on 6-inch or 7-inch frames that benefit from efficient high-KV motors on lower cell counts.
  • FPV drone builds prioritizing durability and smooth performance for aggressive flying and frequent landings.

Technical Specifications

Motor TypeOutrunner Brushless Motor (FPV)
ModelFS 2006 MYTHIC
KV Rating1960 RPM/V
Stator Size20mm x 6mm (2006)
Max Continuous Current23A
Max Power537W
Internal Resistance80.3 mΩ
Shaft MaterialTitanium
Stator Lamination0.15mm Silicon Steel
Recommended LiPo4S-6S
Mounting Hole Pattern16x19mm M3
Shaft Diameter3.175mm (Standard)
Weight (Approx.)45g

Frequently Asked Questions

What is the recommended LiPo voltage range for the MAD Components FS 2006 1960KV motor?

The MAD Components FS 2006 1960KV motor is optimized for 4S to 6S LiPo battery systems (14.8V to 22.2V nominal). Its design provides excellent torque and top-end speed on 4S for agile freestyle, while 6S operation delivers extreme power for high-performance builds. Always pair with a suitably rated ESC (e.g., 35A+).

What are the benefits of the titanium shaft in this motor?

The titanium shaft offers a superior strength-to-weight ratio compared to standard steel. This reduces rotational mass for quicker throttle response, increases durability against bending in crashes, and minimizes unsprung weight, contributing to overall flight efficiency and motor longevity.

What propeller size is suitable for the 2006 1960KV motor?

For 4S operation, propellers in the 4-inch to 5-inch range (e.g., HQProp 5x4.3x3) are ideal. For 5S-6S setups, slightly smaller or less aggressive pitch props (e.g., 5x3x3) are recommended to manage current draw within the motor's 23A continuous rating while still providing massive thrust. Always test with a current meter.

What is the mounting hole pattern for the MAD Components FS 2006 motor?

The MAD Components FS 2006 motor features a standard 16x19mm M3 mounting hole pattern. This is compatible with a wide range of 3-inch, 4-inch, and 5-inch FPV drone frames designed for 20xx and 22xx series motors. Ensure your frame's motor mounting plate supports this pattern.

Package Includes

  • 1 x MAD Components Components FS 2006 MYTHIC FPV Drone Motor (Red) 1960KV

Additional Information

Weight 0.045 kg
Dimensions 6 × 6 × 5 cm
