LWC-GSM-MM-03 GSM Antenna Cable 5m RG58 SMA Male
This LWC-GSM-MM-03 is a 5-meter RG58 coaxial cable with SMA male connectors on both ends, designed for GSM/2G, 3G, and RFID applications across the 824-960MHz and 1710-2170MHz frequency bands.
Features
- 5-meter RG58 coaxial cable assembly with dual SMA male connectors for extended reach.
- Optimized for GSM/2G and 3G frequency bands (824-960MHz & 1710-2170MHz).
- Features a 3/4 dBi gain and a low VSWR of less than 2.0 for efficient signal transfer.
- 50-ohm impedance and 50W power handling for robust RF connectivity.
- Linear polarization suitable for a wide range of mobile communication and RFID devices.
Out of stock
The LWC-GSM-MM-03 (5.0M-RG58) is a purpose-built RF coaxial cable assembly for GSM and 3G network connectivity. Its 5-meter RG58 cable provides flexibility for installations requiring distance between the transceiver and antenna, minimizing signal loss in the 824-960MHz and 1710-2170MHz bands. The assembly ensures reliable performance with standardized 50-ohm impedance and robust SMA male connectors.
Engineered for low VSWR and linear polarization, this cable is ideal for integrating external antennas with GSM modems, IoT gateways, or RFID readers. Its 50-watt power handling and durable construction make it suitable for both indoor and outdoor deployment in telemetry, asset tracking, and mobile communication setups.
Additional Information
| Weight | 0.075 kg |
|---|---|
| Dimensions | 12 × 3 × 2 cm |
