Generic PBS-11B 12mm SPST Momentary Push Button Switch - Red Lock Button
The PBS-11B is a 12mm momentary push button switch with SPST (Single Pole Single Throw) contact configuration, rated for 250V AC / 3A. Featuring a red lock button and a 15mm actuator, it is designed for industrial control panels, machinery, and electronic projects requiring reliable manual input.
Features
- SPST momentary action switch rated for 250V AC / 3A.
- 12mm button diameter with a red lock-style actuator for clear visual indication.
- Mounts via an 18mm panel hole for secure industrial installation.
- Durable mechanical design ensures acute operation and long service life.
- Simple 2-pin connection for straightforward integration into control circuits.
Out of stock
The PBS-11B is a compact, momentary push button switch engineered for industrial control and automation applications. Its SPST (Single Pole Single Throw) contact configuration provides a simple, reliable on/off signal path, activated by pressing the 12mm red button. The switch is housed in a robust body designed for panel mounting via an 18mm hole.
With a robust electrical rating of 250V AC and 3A, this switch is suitable for controlling a wide range of industrial loads directly or through relay circuits. The momentary action ensures the circuit is only closed while the button is depressed, making it ideal for start functions, reset operations, or user input interfaces in machinery, test equipment, and custom control panels.
Additional Information
| Weight | 0.085 kg |
|---|---|
| Dimensions | 10 × 7 × 12 cm |
