Eachine EV800 FPV Goggles - Black
The Eachine EV800 is an entry-level FPV goggle featuring a 5-inch LCD screen with 800×480 resolution and a built-in 5.8GHz 40CH Raceband receiver, designed for immersive analog video reception in drone racing and freestyle applications.
Features
- 5-inch LCD display with 800×480 resolution and 600 cd/m² brightness for clear outdoor viewing.
- Built-in 5.8GHz 40-channel Raceband receiver with auto-scanning for quick frequency acquisition.
- Wide 140° horizontal / 120° vertical field of view for an immersive FPV experience.
- Integrated 3.7V 2000mAh battery and adjustable IPD/head strap for user comfort.
- Supports both NTSC and PAL video formats with a 3x magnification lens system.
Out of stock
The Eachine EV800 FPV Goggles provide a cost-effective entry point into first-person-view drone piloting. The system centers on a vibrant 5-inch LCD panel, delivering a sharp 800×480 resolution image with high brightness to combat outdoor glare. Its integrated 5.8GHz receiver covers the full 40-channel Raceband spectrum, featuring an auto-search function that simplifies the process of locating and locking onto a live video feed from your drone’s VTX.
Ergonomically designed with a soft face foam and a three-point adjustable head strap, the EV800 ensures a comfortable and secure fit for extended flying sessions. The optical lenses offer a 92% transparency rate with adjustable interpupillary distance (IPD), accommodating a wide range of users. The goggles are powered by a built-in 3.7V 2000mAh LiPo battery, providing operational flexibility without the need for an external power source during flight.
Additional Information
| Weight | 0.81 kg |
|---|---|
| Dimensions | 15 × 25 × 11 cm |
