SKU: DRFC-2122
📋 GST Invoice Available

CubePilot Blue V1.1 Video Controller - Black

₹647,729.00 (Inclusive of all taxes)
Out of Stock

The CubePilot Blue V1.1 Video Controller is a long-range HD video transmission ground station designed for UAV and drone operations, featuring a 20km range, 110ms latency, and support for 720p/1080p video feeds.

Features

  • Long-range HD video transmission up to 20km with 110ms latency.
  • Supports 720p 30fps and 1080p 30fps/60fps video formats.
  • Powered by an eight-core S1 processor and Mali-T860 GPU for fast data and image processing.
  • Features dual HDMI inputs for flexible video source connectivity.
  • Compact and portable design with OTA firmware update capability.

Out of stock

Description

The CubePilot Blue V1.1 Video Controller is engineered as a professional-grade ground control station for demanding UAV and drone applications. Its robust transmission system delivers high-definition video with minimal latency, enabling real-time piloting and situational awareness for aerial photography, mapping, and industrial inspections.

Built around a high-performance eight-core processor and dedicated GPU, the unit efficiently handles video encoding, decoding, and analysis. The system’s architecture supports Over-The-Air firmware updates and OEM image customization, allowing for tailored operation and easy integration into specialized workflows.

Key Features

  • Extended 20-kilometer operational range ensures reliable control and video feed in expansive environments.
  • Low-latency 110ms video transmission provides near real-time feedback for precise piloting and navigation.
  • Dual HDMI input ports offer flexibility for connecting multiple video sources or external displays.
  • High-resolution 1280x800 pixel integrated display delivers a clear view of telemetry and video streams.
  • Robust 2.4GHz RF link with FSK modulation and -90dBm sensitivity ensures a stable and interference-resistant control connection.
  • Compact and durable construction, utilizing aluminum alloy and plastic, balances portability with structural integrity.
  • Integrated cooling fan and comprehensive thermal management maintain optimal performance during extended operation.

Applications

  • Long-range FPV piloting and aerial cinematography for professional drones.
  • Remote inspection and monitoring for industrial infrastructure and agricultural surveying.
  • Ground control station for mapping, photogrammetry, and search-and-rescue UAV platforms.
  • Command and control unit for robotic vehicles and remote-operated machinery.

Technical Specifications

ModelCubePilot Blue V1.1 Video Controller
Video Transmission RangeUp to 20 km
Video Latency110 ms
Supported Video Formats720p @ 30fps, 1080p @ 30fps/60fps
Display Resolution1280 x 800 pixels
ProcessorEight-core S1
GPUMali-T860
RF Frequency2.4 GHz
RF ModulationFSK
RF Power1 W
Receiver Sensitivity-90 dBm
Number of Channels2
Input Voltage12V DC
Rated Current2A
Primary MaterialPlastic, Aluminum Alloy
ColorBlack
Diameter67 mm

Frequently Asked Questions

What is the maximum video transmission range and latency of the CubePilot Blue V1.1?

The CubePilot Blue V1.1 Video Controller provides a maximum operational range of up to 20 kilometers under ideal conditions. The system maintains a low video latency of approximately 110 milliseconds, ensuring near real-time feedback for precise piloting and situational awareness during flight.

What video resolutions and frame rates does this ground station support?

This controller supports high-definition video inputs, including 720p at 30 frames per second and 1080p at both 30fps and 60fps. The integrated display has a native resolution of 1280x800 pixels, providing a clear view of the video feed and telemetry data.

What is the input voltage requirement and how is the unit powered?

The CubePilot Blue V1.1 requires a 12V DC power input with a typical current draw of 2A. It is supplied with a 90W wall charger for operation. The system includes comprehensive thermal management with a cooling fan to maintain stability during extended use.

Can the firmware be updated, and does it support customization?

Yes, the controller supports Over-The-Air (OTA) firmware updates for easy software upgrades and feature enhancements. It also offers OEM image support, allowing for deep customization and tailored operation to fit specific application requirements or integration into proprietary systems.

Package Includes

  • 1 x CubePilot Blue Ground Station
  • 2 x CubePilot Blue Controller Joystick
  • 1 x HDMI Cable
  • 1 x 90W Wall Charger
  • 1 x Air Unit Wire Harness Kit
  • 1 x Micro USB Cable
  • 2 x Controller Antenna
  • 1 x Air Unit Mounting Plate & Fan Hardware Kit
  • 1 x Air Unit Cooling Fan
  • 2 x Neck Lanyard Clip
  • 1 x Air Unit Antenna

Additional Information

Weight 3.65 kg
Dimensions 34 × 30 × 14 cm
