AxisFlying C246 240 Brushless Motor 1650KV

Name: AxisFlying C246 240 Brushless Motor 1650KV
Brand: AxisFlying
SKU: DRFC-2781
Price: 1649.00 INR
Availability: OutOfStock

₹1,649.00 (Inclusive of all taxes)

Out of Stock

The AxisFlying C246 240 brushless motor is a 1650KV unit engineered for 5-6 inch freestyle and cinematic FPV drones, offering high thrust and smooth power delivery on 6S LiPo systems.

Features

1650KV rating optimized for high-thrust 5-6 inch propeller setups on 6S LiPo.
24mm stator diameter and 6mm stator height for a balanced power-to-weight ratio.
Robust construction with a 5mm shaft and 16x16mm mounting pattern for durability.
Advanced cooling system manages heat during prolonged, high-current operation.
Delivers 45A continuous current for responsive freestyle and stable cinematic flight.

Out of stock

Get Notified When Available

Description

The AxisFlying C246 240 motor is designed for pilots seeking a blend of aggressive power and controlled delivery for dynamic FPV flying. Its 1650KV winding is specifically tuned for 6S voltage, providing the torque necessary for quick acceleration and recovery in freestyle maneuvers while maintaining the smoothness required for cinematic footage.

Built around a 24mm stator, the motor employs high-grade materials and precision machining to ensure consistent performance and impact resistance. The integrated cooling architecture promotes efficient heat dissipation, supporting sustained high-current draws up to 45A continuous, which is critical for demanding Sbang and aggressive freestyle sequences.

Key Features

Optimized 1650KV Winding: Engineered for 6S LiPo systems, delivering an ideal balance of high torque and efficient RPM for 5-6 inch props.
Durable Stator Construction: Features a 24mm diameter and 6mm height stator using high-quality laminations and windings for reliable power output.
Enhanced Thermal Management: Motor bell and stator design promotes airflow to reduce operating temperatures during extended flight sessions.
Standardized Mounting: 16x16mm M3 mounting pattern and 5mm shaft diameter ensure broad compatibility with popular FPV frames and propellers.
High-Current Capability: Rated for 45A continuous current, supporting aggressive throttle punches and sustained high-power maneuvers.
Precision Balanced: Factory-balanced rotor assembly minimizes vibrations for smoother video footage and reduced frame stress.

Applications

5-inch and 6-inch FPV freestyle quadcopters requiring high thrust for aggressive maneuvers and dives.
Sbang and flow-style FPV builds where consistent power delivery and quick directional changes are essential.
Cinematic FPV drones (5-6 inch) used for smooth, stable aerial videography on 6S power systems.
Long-range endurance builds optimized for 6S setups that benefit from the motor's efficient power band.

Technical Specifications

Model	AxisFlying C246 240
Motor Type	Outrunner Brushless
KV Rating	1650 KV
Stator Dimensions	24mm x 6mm
Shaft Diameter	5 mm
Mounting Pattern	16x16mm (M3)
Continuous Current	45 A
Max Voltage	25.2 V (6S LiPo)
Weight	34 g
Recommended Prop Size	5-6 inch

Frequently Asked Questions

What is the recommended battery and propeller size for the AxisFlying C246 1650KV motor?

This motor is optimized for 6S LiPo batteries (max 25.2V) and is best paired with 5-inch or 6-inch bi-blade or tri-blade propellers. Using the correct prop size ensures optimal thrust, efficiency, and prevents the motor from overheating during high-throttle flight.

What is the mounting pattern and shaft size?

The AxisFlying C246 motor uses a standard 16x16mm M3 mounting pattern, compatible with most 5-inch and 6-inch FPV frames. It features a 5mm diameter shaft, which is common for motors in this size class and ensures secure propeller attachment.

What is the continuous current rating, and what ESC is recommended?

The motor has a continuous current rating of 45A. For reliable performance, especially during aggressive freestyle, it is recommended to use a 4-in-1 ESC or individual ESCs rated for at least 50A continuous per motor to provide adequate headroom and prevent premature failure.

Is this motor suitable for long-range or cinematic FPV flying?

Yes, the 1650KV rating on 6S provides a good balance of power and efficiency, making it well-suited for smooth cinematic flying and long-range endurance flights where controlled throttle management is key. Its design offers stable performance for carrying payloads like action cameras.
