AxisFlying AE2306.5 V2 1860KV Brushless Motor - 5-Inch FPV Freestyle
The AxisFlying AE2306.5 V2 is a 1860KV brushless motor engineered for 5-inch FPV freestyle drones, delivering 859W of continuous power for aggressive maneuvers like Arco and Flow. Its 12N14P configuration and low 70.62 mΩ resistance ensure efficient, responsive performance on 4S to 6S LiPo systems.
Features
- High-Power 1860KV Motor optimized for 5-inch FPV freestyle and racing quads.
- Delivers 859.58W max continuous power and up to 1670g of thrust per motor.
- Low 70.62 mΩ interphase resistance for efficient operation and extended flight times.
- Lightweight 33.7g design with a 12N14P magnetic configuration for smooth torque.
- Compatible with 4S-6S LiPo batteries, supporting a max current draw of 36.86A.
Out of stock
The AxisFlying AE2306.5 V2 brushless motor represents a refined balance of power, weight, and durability for modern 5-inch FPV builds. Its 2306.5 stator size provides a substantial magnetic field for high torque, while the 1860KV rating is tuned for dynamic throttle response across 4S to 6S voltage ranges, making it ideal for technical freestyle and high-speed cruising.
Constructed with a robust 12N14P (12 stator poles, 14 magnet poles) design, the motor ensures smooth rotation and reduced cogging torque. The low interphase resistance minimizes electrical losses, translating battery energy directly into thrust and improving overall system efficiency. The motor’s housing is engineered for optimal thermal dissipation, maintaining consistent performance during prolonged, aggressive flight sessions.
Additional Information
| Weight | 0.34 kg |
|---|---|
| Dimensions | 13 × 9 × 7 cm |
