Surpass Hobby 80A 2-6S SBEC ESC w/ 4.0mm Connector
Surpass Hobby 80A 2-6S SBEC ESC w/ 4.0mm Connector - Image 2
SKU: DRFC-0104
📋 GST Invoice Available

Surpass Hobby 80A 2-6S SBEC ESC w/ 4.0mm Connector

₹3,619.00 (Inclusive of all taxes)
Out of Stock

This Surpass Hobby 80A ESC provides robust power control for RC aircraft, supporting 2-6S LiPo batteries and delivering stable 5V/6V SBEC output for onboard electronics. Engineered for dependable performance, it is suitable for a wide range of fixed-wing and multi-rotor applications.

Features

  • 80A continuous, 100A burst current handling for demanding RC applications.
  • Wide 2-6S LiPo and 5-18NC NiMH battery compatibility.
  • Integrated 5V/6V @ 5A Switch-mode SBEC for reliable power to servos and receivers.
  • Compact 90x37x10mm design with 4.0mm connectors for easy integration.

Out of stock

Description

The Surpass Hobby 80A ESC is a high-performance electronic speed controller designed for RC aircraft, providing precise motor control and dependable operation. With its robust design and versatile features, this ESC is engineered to deliver an enhanced flying experience across a wide range of fixed-wing and multi-rotor applications.

Its architecture focuses on durability, utilizing high-quality components to withstand the demands of intense RC flight. The integrated Switch-mode Battery Eliminator Circuit (SBEC) ensures a stable and regulated power supply for critical onboard electronics, further contributing to the overall reliability and performance of your aircraft’s control systems.

Key Features

  • Wide Battery Compatibility: Supports LiPo batteries ranging from 2 to 6 cells and NiMH batteries from 5 to 18 cells, offering broad flexibility for various aircraft setups and flight durations.
  • Switch-mode SBEC: Equipped with a powerful Switch-mode Battery Eliminator Circuit (SBEC) capable of delivering stable output voltages of 5V or 6V at up to 5A, accommodating diverse power requirements for onboard electronics like servos and receivers.
  • Robust Construction: Designed with durability in mind, this ESC features high-quality components and construction to consistently withstand the demands of rigorous RC flight.
  • Compact & Efficient Design: With dimensions of 90mm x 37mm x 10mm, this ESC fits neatly into most aircraft configurations, optimizing space utilization and minimizing overall weight for improved flight performance.
  • Secure 4.0mm Connector: Features a standard 4.0mm connector for secure and efficient connections to the motor and battery, ensuring reliable power transmission and reducing the risk of connectivity issues during flight.

Applications

  • FPV fixed-wing aircraft
  • RC multi-rotor drones
  • General hobbyist and sport RC planes

Technical Specifications

BrandSurpass Hobby
Continuous Current80A
Burst Current100A (10 seconds)
Battery CompatibilityLiPo 2-6S (7.4V-22.2V), NiMH 5-18NC
SBEC Output5V/6V @ 5A (Switch-mode)
Dimensions (LxWxH)90mm x 37mm x 10mm
Connector Type4.0mm

Frequently Asked Questions

What battery types and voltages does the Surpass Hobby 80A ESC support?

The ESC is compatible with 2-6S LiPo batteries, providing an input voltage range from 7.4V to 22.2V. Additionally, it supports 5-18NC NiMH battery configurations, offering broad flexibility for various RC aircraft power setups. This wide compatibility ensures versatility across different models and flight requirements.

What is the function of the integrated SBEC on this ESC?

The built-in Switch-mode Battery Eliminator Circuit (SBEC) provides a stable regulated power output of either 5V or 6V, delivering up to 5A. This power is crucial for safely operating onboard electronics such as servos, receivers, and flight controllers, bypassing the need for a separate BEC and simplifying wiring.

How does the Surpass Hobby 80A ESC ensure reliable power connections?

This ESC is equipped with a robust 4.0mm connector, designed for secure and efficient electrical connections to your motor and battery. This standard ensures minimal resistance and reliable power transmission, reducing the risk of accidental disconnections or power loss during demanding flight maneuvers, enhancing safety and performance.

What are the continuous and burst current ratings of this 80A ESC?

The Surpass Hobby 80A ESC is rated for a continuous current of 80 amperes, making it suitable for a wide range of RC aircraft and demanding propulsion systems. It can also handle burst currents of up to 100 amperes for a duration of 10 seconds, providing crucial extra power for short, intense maneuvers.

Package Includes

  • 1 x Surpass Hobby 80A ESC (2-6S LiPo, 5-18NC NiMH, SBEC: 5V/6V @ 8A, 90x37x10mm, 4.0 Connector)

Additional Information

Dimensions 9 × 3.7 × 1 cm
