SKU: 3DDF-0047
📋 GST Invoice Available

Anycubic Wash & Cure 3

₹9,999.00 (Inclusive of all taxes)
Out of Stock

The Anycubic Wash & Cure 3 provides a comprehensive, upgraded post-processing solution for resin 3D prints. This versatile machine efficiently cleans and cures models up to 160 x 180 mm, featuring enhanced capacity and superior light uniformity for optimal results.

Features

  • Upgraded Capacity: Accommodates larger prints, cleaning and curing models up to 160 x 180 mm with a 15% increased curing space.
  • Enhanced Curing Uniformity: Features a redesigned light bead arrangement and lens light source, improving curing uniformity by 20% for thorough model hardening.
  • Precision Gooseneck UV Light: Delivers an additional 30,000 uW/cm² energy to fine details, ensuring complete curing of intricate model areas.
  • Intuitive Dual Mode Operation: Offers one-click switching between washing and curing functions, alongside an adjustable timer for precise control.
  • IPA-Efficient Cleaning: Utilizes a dual-layered PP cleaning basket with adjustable heights to maximize IPA effectiveness and accommodate various print platforms.

Out of stock

Description

The Anycubic Wash & Cure 3 represents a significant upgrade in post-processing for resin 3D printing, combining efficient cleaning and UV curing into a single, user-friendly unit. Designed for both hobbyists and professionals, this machine streamlines the often-messy post-print workflow, ensuring your resin models transition from raw prints to ready-to-use parts with minimal effort and maximum quality. Its robust design addresses the common challenges of resin printing, providing a clean, consistent, and safe environment for finishing models.

This system is essential for achieving professional-grade results, replacing manual cleaning and inconsistent curing methods. By integrating both wash and cure functions, it not only saves valuable workspace but also ensures consistent exposure to UV light and thorough removal of uncured resin, which is crucial for the durability and aesthetic quality of your finished prints. The enhanced features, such as increased capacity and specialized gooseneck lighting, guarantee that even complex and larger models receive optimal treatment, preventing issues like sticky surfaces or incomplete curing that can compromise print integrity.

The Wash & Cure 3 improves overall printing accuracy by providing a reliable and uniform curing process. Proper curing strengthens the resin, increasing the part’s mechanical properties and preventing degradation over time. Its user-centric design, featuring simple one-click operations and adjustable timing, ensures that maintaining your resin prints is no longer a chore but an integrated, efficient step in your additive manufacturing process.

Key Features

  • Enhanced Curing Volume: Offers a curing space of 160 x 180 mm, representing a 15% increase over previous models, allowing for larger and more batch processing.
  • Optimized UV Light Uniformity: Utilizes a new arrangement of light beads and a lens light source, achieving a 20% improvement in curing uniformity for consistent resin hardening.
  • Targeted Gooseneck UV LED: Equipped with a flexible gooseneck light that adds 30,000 uW/cm² of UV energy within 1-3 cm, ideal for meticulously curing intricate details and hard-to-reach areas.
  • Intuitive One-Click Operation: Streamlined interface provides easy selection of cleaning and curing modes with a single click, enhancing user convenience.
  • Adjustable Cycle Timer: Features an infinite rotary knob for setting wash and cure times from 1 to 30 minutes, offering precise control for various resin types and model sizes.
  • Efficient Dual-Layer Cleaning Basket: Includes a PP material cleaning basket with dual layers, designed to support simultaneous cleaning with the print platform and optimize IPA usage.
  • Flexible Basket Height Settings: The cleaning basket offers adjustable heights (100mm, 165mm) to accommodate print platforms ranging from 5.9" to 7.3".
  • Integrated Washing & Curing: Combines both essential post-processing steps into a single compact unit, saving space and simplifying workflow.

Technical Specifications

Model No. / NameWash and Cure 3
Machine Size (mm)216 x 217 x 310
Light Source10pcs 405nm UV + Gooseneck Light
Weight (Kg)
Shipping Weight2.8 kg
Shipping Dimensions45 × 30 × 30 cm

Frequently Asked Questions

What is the maximum processing size for models in the Anycubic Wash & Cure 3?

The Anycubic Wash & Cure 3 is designed to efficiently clean and cure resin 3D models with dimensions up to 160 mm x 180 mm (diameter x height). This capacity allows for post-processing of a wide range of standard resin prints, ensuring thorough treatment and optimal results.

What type of light source is used for curing, and how does it ensure uniformity?

The Wash & Cure 3 utilizes 10 pieces of 405nm UV light combined with a flexible gooseneck light for comprehensive curing. This setup provides enhanced light uniformity, ensuring that all surfaces of the resin print receive adequate UV exposure for a consistent and complete cure.

Can the Anycubic Wash & Cure 3 accommodate different types of resin 3D prints?

Yes, the Anycubic Wash & Cure 3 is compatible with most standard UV-curable resin 3D prints. Its efficient cleaning mechanism removes uncured resin, while the uniform UV curing process post-hardens models, making it suitable for a broad spectrum of SLA, DLP, and LCD resin applications.

What are the physical dimensions and weight of the Anycubic Wash & Cure 3 machine?

The physical dimensions of the Anycubic Wash & Cure 3 machine are 216 mm (length) x 217 mm (width) x 310 mm (height). The shipping weight for the unit is approximately 2.8 kg, with shipping dimensions of 45 × 30 × 30 cm.

Package Includes

  • 1 x Anycubic Wash & Cure 3

Additional Information

Weight 2.8 kg
Dimensions 30 × 45 × 30 cm
