Arducam IMX708 12MP NoIR Autofocus Wide-Angle Camera for Raspberry Pi

Description

The Arducam IMX708 12MP NoIR Autofocus Wide-Angle Camera Module 3 integrates Sony’s advanced 1/2.43-inch back-illuminated CMOS sensor, providing 11.9-megapixel resolution (4608×2592) for high-fidelity image capture. Its 2.75mm focal length wide-angle lens offers a 120-degree diagonal field of view, making it suitable for expansive scene monitoring in robotics, surveillance, and creative vision projects.

Engineered for the Raspberry Pi ecosystem, this module connects via a standard 22-pin FPC interface and operates at 3.3V with a maximum power consumption of 1.16W. The fast Phase Detection Autofocus (PDAF) ensures quick and accurate focus from 5cm to infinity, while the NoIR design removes the IR-cut filter for enhanced sensitivity to infrared light, unlocking applications in astrophotography and night vision. The compact 24x25mm form factor allows for easy integration into embedded and DIY builds.
