The T-Motor Velox V2808 is a 1300KV brushless motor engineered for 4-5 inch Cinewhoop and FPV racing drones, offering smooth, controlled power delivery across a 4S to 6S LiPo voltage range for stable, high-quality aerial footage.

Features

1300KV rating optimized for smooth, efficient power delivery on 4-5 inch Cinewhoop and racing frames.
Wide 4S to 6S LiPo battery compatibility for flexible power system integration.
Premium construction with a 60.3g weight for a durable and responsive flight performance.
16x19mm (M3) mounting pattern for broad compatibility with standard 4-5 inch drone frames.
Designed for low-noise operation and extended flight times in cinematic and racing applications.

Out of stock

Get Notified When Available

Description

The Velox V2808 from T-Motor is a purpose-built brushless motor designed to meet the specific demands of 4-5 inch Cinewhoop and FPV racing platforms. Its 1300KV rating provides a balanced torque-to-RPM profile, delivering smooth and controllable thrust essential for stable, vibration-free video capture and precise racing maneuvers.

Engineered for durability, the motor features high-quality bearings, a robust stator, and efficient cooling to handle continuous 30A current loads. The optimized magnetic circuit and winding design minimize electrical noise and maximize efficiency, contributing to longer flight times and reliable performance across its full 4S to 6S operating range.

Key Features

Optimized KV for Cinewhoops: 1300KV rating delivers the ideal balance of torque and RPM for smooth, controlled flight on 4-5 inch propellers.
Extended Voltage Range: Supports 4S to 6S LiPo batteries, allowing for flexible power system builds and performance tuning.
High-Efficiency Design: Precision windings and magnetic circuit minimize power loss and heat generation for extended flight endurance.
Robust Mechanical Construction: Features durable bearings and a reinforced stator for reliable operation under high loads.
Standard Mounting Pattern: 16x19mm (M3) hole spacing ensures compatibility with a wide range of popular 4-5 inch drone frames.
Lightweight Performance: At 60.3 grams, it provides an excellent thrust-to-weight ratio for agile and responsive flight characteristics.

Applications

4-inch and 5-inch Cinewhoop builds requiring smooth, stable power for cinematic FPV footage.
Lightweight 5-inch FPV racing drones where efficient, controllable thrust is prioritized.
Long-range or endurance-focused 4-5 inch FPV platforms benefiting from the motor's efficiency on 4S-6S.
Freestyle drone builds in the 4-5 inch category where a balance of power and flight time is desired.

Technical Specifications

Model	T-Motor Velox V2808
KV Rating	1300 KV
Max Current	30 A
Voltage Range	4-6S LiPo
Motor Type	Outrunner Brushless
Weight	60.3 g
Mounting Pattern	16x19mm (M3)
Shaft Diameter	5mm (Typical for V2808)
Stator Size	28mm (D) x 8mm (H)

Frequently Asked Questions

What size propellers are recommended for the T-Motor Velox V2808 1300KV motor?

This motor is optimized for 4-inch and 5-inch propellers, typical for Cinewhoop and racing drone frames. For 4S setups, 5-inch bi-blade or tri-blade props are common. On 6S, you may need to use slightly smaller or lower-pitch 5-inch props to manage current draw effectively.

Is the Velox V2808 compatible with standard 30.5x30.5mm flight controller mounting?

No, the motor itself has a 16x19mm (M3) mounting pattern for attaching to the drone's arms. The 30.5x30.5mm pattern refers to flight controller and ESC stack mounting, which is separate. Ensure your frame's motor mounting holes match the 16x19mm spacing.

What is the maximum recommended ESC current rating for use with this motor?

Given the motor's 30A max current specification, it is advisable to use Electronic Speed Controllers (ESCs) rated for at least 35A to 40A continuous current per motor. This provides a safe overhead margin, especially for aggressive flying or when using high-pitch propellers on 6S voltage.
