Raise3D E2 Desktop FDM 3D Printer with Dual Extruders

₹309,048.00 (Inclusive of all taxes)
Out of Stock

The Raise3D E2 is an advanced desktop FDM 3D printer featuring Independent Dual Extruders (IDEX) for efficient duplication and mirror printing modes. Its flexible build plate ensures easy print removal, while broad material compatibility and integrated software streamline your entire 3D printing workflow.

Features

  • IDEX System: Achieve twice the output with Mirror and Duplication modes.
  • Flexible Build Plate: Simplifies print removal, reducing part damage.
  • Wide Material Compatibility: Supports 15+ filaments, including engineering-grade materials.
  • Integrated Workflow: Seamlessly manage prints with RaiseCloud and ideaMaker software.
  • Enhanced Safety: Auto-pause feature when the door opens, ensuring secure operation.

Out of stock

Description

The Raise3D E2 stands out as a professional-grade desktop FDM 3D printer, distinguished by its Independent Dual Extruders (IDEX). This innovative system enables advanced capabilities such as Mirror and Duplication Modes, effectively halving print times for batch production and facilitating complex multi-material projects without cross-contamination. Its robust design incorporates features like automatic bed leveling and a flexible BuildTak FlexPlate, ensuring excellent first-layer adhesion and effortless print removal.

Designed for reliability and performance, the E2 offers broad material compatibility, supporting a wide array of filaments from PLA to engineering-grade composites. Connectivity options, including Wi-Fi and RaiseCloud, provide seamless workflow integration and remote monitoring. The fully enclosed build chamber maintains consistent temperatures and features HEPA air filtration for a safer working environment. With a user-friendly 7-inch touchscreen, the Raise3D E2 delivers industrial-grade results, making it an ideal choice for engineering, education, and rapid prototyping applications.

Key Features

  • IDEX System: Enables Mirror and Duplication printing modes for enhanced productivity.
  • Easy Swap Print Heads: Facilitates quick changes for different nozzle types and simplified maintenance.
  • Auto Bed Leveling: Ensures optimal first-layer adhesion and consistent print quality across the build plate.
  • Flexible Build Plate: Allows for easy and damage-free removal of completed 3D prints.
  • Wide Material Compatibility: Supports a diverse range of filaments including PLA, ABS, TPU, Nylon, and various composites.
  • Camera Monitoring: Provides real-time remote surveillance of print progress via RaiseCloud.
  • Power Loss & Filament Run-Out Recovery: Protects prints from interruptions, ensuring job completion.
  • HEPA Air Filtration: Reduces emissions and improves air quality within the operational environment.

Applications

  • Rapid Prototyping: Quickly iterate and test design concepts with high accuracy.
  • Engineering & Manufacturing: Produce functional parts, jigs, fixtures, and tooling with diverse materials.
  • Educational Institutions: Ideal for teaching advanced additive manufacturing concepts and hands-on projects.
  • Batch Production: Utilize IDEX duplication mode for efficient small to medium-batch part manufacturing.
  • Multi-Material Projects: Create complex prints with soluble supports or different material properties using IDEX.

Technical Specifications

Printer TypeFDM (Fused Deposition Modeling)
Build Volume (L×W×H)295 × 240 × 240 mm (Single Extruder)
Supported FilamentsPLA, ABS, ASA, PETG, PC, PETG ESD, TPU 95A, PVA+
Nozzle Diameter0.4 mm (Default), 0.6 mm, 0.8 mm (Available)
Max Hotend Temperature300 °C
ConnectivityWi-Fi, LAN, USB Port, Live Camera
Machine Dimensions (L×W×H)607 × 596 × 465 mm
Printing Speed15-150 mm/s
Input Voltage100–240 V
Output Voltage24 V

Frequently Asked Questions

What are the main benefits of the IDEX system on the Raise3D E2?

The Independent Dual Extruder (IDEX) system on the Raise3D E2 enables Mirror and Duplication printing modes. This allows for simultaneous printing of two identical or mirrored objects, significantly increasing throughput for batch production or reducing print times for large projects, while preventing cross-contamination between materials.

What types of materials can the Raise3D E2 print?

The Raise3D E2 is highly versatile, supporting a wide range of filaments. It can print common materials like PLA, ABS, ASA, and PETG, as well as engineering-grade filaments such as PC, PETG ESD, TPU 95A, and PVA+ for soluble supports. Its 300°C hotend temperature accommodates these diverse material requirements.

What are the key connectivity and monitoring features of the E2?

The E2 offers robust connectivity options including Wi-Fi, LAN, and USB port for flexible data transfer. It also features an integrated live camera, allowing users to remotely monitor print progress via RaiseCloud. This enables efficient workflow management and real-time oversight of ongoing print jobs from anywhere.

Does the Raise3D E2 have features for print reliability and safety?

Yes, the Raise3D E2 includes several features to enhance reliability and safety. It has power loss recovery, filament run-out detection to prevent failed prints, and auto bed leveling for consistent first layers. For safety, it features an auto-pause function when the door opens and a HEPA air filtration system to reduce emissions.

Package Includes

  • 1 x Raise3D E2 Desktop 3D Printer with Dual Extruders

Additional Information

Weight 35.6 kg
Dimensions 60.7 × 59.6 × 46.5 cm
