Pro-Range D63 Ducted PC 3-Blade 1.5mm Propellers 4CW+4CCW - Clear Gray

Name: Pro-Range D63 Ducted PC 3-Blade 1.5mm Propellers 4CW+4CCW - Clear Gray
Brand: Pro-Range
SKU: DRFC-1167
Price: 279.00 INR
Availability: OutOfStock

₹279.00 (Inclusive of all taxes)

Out of Stock

The Pro-Range D63 is a set of 63mm ducted, three-blade propellers crafted from durable Polycarbonate (PC) with a 1.5mm center hole. Designed for 1204 and larger motors, these props offer a balanced combination of thrust and efficiency for compact FPV drones and CineWhoops.

Features

Ducted 63mm (D63) three-blade propeller design for Whoop and CineWhoop frames.
Constructed from durable Polycarbonate (PC) for a high strength-to-weight ratio.
1.5mm center hole with 3-hole mounting pattern for secure attachment to 1204+ motors.
Includes a balanced 4CW + 4CCW set for immediate replacement and tuning.
Clear Gray finish provides a sleek, semi-transparent aesthetic.

Out of stock

Get Notified When Available

Description

The Pro-Range D63 propellers are engineered for ducted micro and CineWhoop drone applications, where propeller guards are integral to the frame. The 63mm diameter and three-blade configuration are optimized to generate efficient thrust within the physical constraints of a duct, balancing performance with the protection needed for indoor and proximity flying.

Made from injection-molded Polycarbonate, these blades offer significant durability against impacts while maintaining a low rotational mass for responsive motor control. The precise 1.5mm shaft hole and three-bolt pattern ensure a secure, concentric mount, critical for minimizing vibrations and achieving smooth flight characteristics on Betaflight or EmuFlight-equipped drones.

Key Features

Ducted propeller design (63mm) specifically for Whoop and micro CineWhoop frames.
Polycarbonate (PC) construction delivers impact resistance and flight durability.
Precision-balanced blades from the factory reduce vibration for cleaner video feed.
1.5mm center hole diameter with a 3-hole mounting pattern for 1204 and larger brushless motors.
Includes a complete 8-propeller set (4CW + 4CCW) for full quadcopter replacement.
Clear Gray polycarbonate offers a distinctive, semi-transparent look.

Applications

3-inch CineWhoop and ducted FPV drones for cinematic indoor/outdoor flying.
Micro Whoop builds (e.g., Mobula7, Tinyhawk III) requiring 63mm ducted props.
Lightweight freestyle and proximity flying in tight spaces.
Replacement propellers for drones using 1204, 1303, or 1404 brushless motors with a 1.5mm shaft.

Technical Specifications

Model Series	D63
Propeller Type	Ducted
Diameter	63mm
Blade Count	3
Material	Polycarbonate (PC)
Rotation Direction	CW & CCW
Pitch	3.0 inch (as per spec list)
Center Hole Diameter	1.5mm
Mounting Holes	3-hole pattern
Compatible Motor Size	1204 and larger
Color	Clear Gray
Set Configuration	4CW + 4CCW (8 total)

Frequently Asked Questions

What motor size are these D63 propellers compatible with?

These propellers are designed for motors sized 1204 and larger. The critical compatibility factor is the 1.5mm center hole diameter and the 3-hole mounting pattern. Always verify your motor's shaft diameter and bolt pattern match these specs before installation.

Are these propellers balanced out of the package?

Pro-Range propellers undergo factory balancing for consistent performance. However, for competitive racing or ultra-smooth HD video, it is recommended to perform a final dynamic balance check using a propeller balancer, as minor variances can occur.

Can I use these on a 2S or 3S LiPo powered Whoop?

Yes. These Polycarbonate D63 props are suitable for typical 2S and 3S power systems used in micro and CineWhoop drones. Ensure your 1204 or larger motors are rated for the KV appropriate to your battery voltage to avoid over-propping and excessive current draw.
