Pimoroni Touch pHAT for Raspberry Pi

₹919.00 (Inclusive of all taxes)
Out of Stock

The Pimoroni Touch pHAT provides six capacitive touch buttons with integrated LEDs for Raspberry Pi boards featuring a 40-pin GPIO header. Utilizing the CAP1166 driver IC, it offers an intuitive and easy-to-assemble input solution for various projects.

Features

  • Features six capacitive touch buttons with integrated white LEDs.
  • Utilizes the CAP1166 capacitive touch and LED driver chip for responsive input.
  • Fully compatible with all Raspberry Pi models equipped with a 40-pin GPIO header.
  • Provides a simple and intuitive way to add interactive input to your projects.

Out of stock

Description

The Pimoroni Touch pHAT extends your Raspberry Pi’s capabilities with six responsive capacitive touch buttons, each complemented by a bright, under-mounted white LED. Designed for versatility, these touchpads can be customized with dry erase markers for specific functions, making them ideal for a wide range of interactive projects.

At its core, the Touch pHAT is powered by the Microchip Technology CAP1166 capacitive touch and LED driver IC, ensuring precise and reliable input detection. The innovative under-mounted LEDs emit a subtle yellow-green glow through the PCB, maintaining a smooth top surface while providing visual feedback. This design facilitates integration into applications requiring intuitive user interfaces, from robotics control to custom gaming setups and smart home automation.

Key Features

  • Integrates six individual capacitive touch buttons for versatile user input.
  • Each button is paired with a bright white under-mounted LED for clear visual feedback.
  • Leverages the Microchip Technology CAP1166 capacitive touch and LED driver chip for robust performance.
  • Designed for full compatibility with any Raspberry Pi model featuring a standard 40-pin GPIO header.
  • The included 40-pin female header requires soldering for secure attachment to the Raspberry Pi.
  • Allows for custom labeling of touchpads using dry erase markers for specific application contexts.

Applications

  • Robotics control interfaces and remote command systems.
  • Interactive control panels for smart home automation or IoT devices.
  • Custom gaming controllers or input devices for mini-games.
  • DIY musical instruments like a tiny drum machine or synthesizer pads.
  • Educational projects demonstrating capacitive touch sensing and LED control.

Technical Specifications

Form FactorpHAT (Partial HAT)
CompatibilityRaspberry Pi (all 40-pin GPIO models)
Touch ControllerMicrochip Technology CAP1166
Input Type6x Capacitive Touch Buttons
Feedback6x White Under-Mounted LEDs
Length65 mm
Width30 mm
Operating Voltage3.3V (from Raspberry Pi GPIO)
InterfaceI2C

Frequently Asked Questions

What Raspberry Pi models are compatible with the Touch pHAT?

The Pimoroni Touch pHAT is compatible with any Raspberry Pi board that features the standard 40-pin GPIO header. This includes models like the Raspberry Pi 3B+, 4B, Zero W, and 5. Ensure the female header is soldered correctly for a secure electrical connection to the GPIO pins.

How does the CAP1166 driver chip function on the Touch pHAT?

The CAP1166 is a capacitive touch and LED driver chip that manages both the touch sensing and LED control for the six buttons. It communicates with the Raspberry Pi via the I2C interface, providing touch event data and receiving commands to control the brightness or state of the under-mounted white LEDs.

What software libraries or tools are recommended for using the Touch pHAT?

Pimoroni provides a comprehensive Python library for the Touch pHAT, which simplifies interaction with the CAP1166 chip. This library allows easy detection of touch events, control of individual LEDs, and integration into various Python-based Raspberry Pi projects. It can be installed using pip.

Does the Touch pHAT require any soldering?

Yes, the Pimoroni Touch pHAT includes an unassembled 40-pin female header. This header must be soldered onto the pHAT board to enable connection with the Raspberry Pi's GPIO pins. This process ensures a robust and reliable physical and electrical connection for the board's functionality.

Package Includes

  • 1x Pimoroni Touch pHAT Board
  • 1x 40-Pin Female Header (unassembled)

Additional Information

Weight 0.0104 kg
Dimensions 6.5 × 3 cm
