MAD Components Components XC5000 POLAR Brushless Motor 345KV
The MAD Components Components XC5000 POLAR is a high-performance 345KV brushless motor engineered for demanding industrial and enterprise UAV applications, supporting 10-12S LiPo battery systems for heavy-lift and VTOL platforms.
Features
- High-torque 345KV design optimized for 10-12S LiPo voltage range.
- Delivers up to 2929W maximum power and 1.9Nm peak torque.
- Robust construction with three durable bearings for extended operational life.
- Capable of generating a maximum thrust of 6.1kg per motor.
- Designed for large-scale multirotors, VTOL, and agricultural drones.
Out of stock
The XC5000 POLAR brushless motor from MAD Components Components is engineered for the most demanding aerial platforms, including high-end X-class drones, VTOL aircraft, and agricultural copters. Its 345KV rating and low internal resistance of 60mOhm are optimized for efficient operation on 10-12S LiPo battery systems, providing the high torque and power density required for payloads of 2-3kg per rotor.
Built with durability in mind, the motor features a robust stator and rotor assembly supported by three precision bearings, ensuring smooth operation and longevity under continuous high-load conditions. With a peak power output of 2929W and a maximum thrust of 6.1kg, it is a cornerstone component for builders of 800-1200mm multirotor aircraft requiring reliable and powerful propulsion.
Additional Information
| Weight | 0.56 kg |
|---|---|
| Dimensions | 12 × 12 × 11 cm |
