MAD Components Components FS 2207.5 Turbo FPV Drone Motor 1750KV-6S - Red

The MAD Components Components FS 2207.5 1750KV motor is optimized for 4S to 6S LiPo batteries (14.8V to 22.2V). On 6S, it will deliver maximum power and top speed for freestyle, while 4S operation provides a more manageable power band for lighter builds or pilots seeking longer flight times. Always ensure your Electronic Speed Controllers (ESCs) are rated for the same voltage range.

This motor uses the standard 16x19mm M3 mounting hole pattern, compatible with most 5-inch FPV frames. The shaft diameter is 3.175mm (1/8 inch), which is standard for 5-inch propellers and uses an M5 threaded prop nut. Ensure your frame's motor mounting holes align with the 16x19mm pattern.

The titanium shaft is significantly stronger and lighter than standard steel shafts, reducing rotational mass for faster throttle response and improved durability against crashes. The 0.15mm thin silicon steel stator laminations reduce eddy current losses within the motor, improving electrical efficiency. This results in cooler operating temperatures, less wasted energy, and potentially longer flight times.

Yes, this is a standard 3-phase brushless motor compatible with any BLHeli_S, BLHeli_32, or AM32-based ESC that can handle its 36A maximum current draw. It will work seamlessly with Betaflight, EmuFlight, and other flight controllers. Just ensure your ESC firmware is properly configured for your desired motor timing and PWM frequency.
