MAD Components Components FS 2204 ELITE FPV Motor 2750KV - 6S - Green
MAD Components Components FS 2204 ELITE FPV Motor 2750KV - 6S - Green - Image 2
SKU: DRFC-2537
📋 GST Invoice Available

MAD Components Components FS 2204 ELITE FPV Motor 2750KV - 6S - Green

₹1,799.00 (Inclusive of all taxes)
Out of Stock

The MAD Components Components FS 2204 ELITE is a high-performance 2750KV brushless motor engineered for 6S-powered FPV freestyle drones, delivering 740g of max thrust with a lightweight titanium shaft and high-efficiency silicon steel laminations.

Features

  • 2750KV rating optimized for high-RPM 6S LiPo performance.
  • Lightweight titanium shaft for reduced rotational mass and increased durability.
  • 0.15mm silicon steel stator laminations for improved electromagnetic efficiency and reduced iron losses.
  • Maximum thrust output of 740g per motor for aggressive freestyle maneuvers.
  • Secondary anodized finish for corrosion resistance and a premium aesthetic.

Out of stock

Description

The FS 2204 ELITE motor from MAD Components Components represents a focused development for the FPV freestyle segment. Its core engineering advancements include a titanium shaft, which significantly lowers rotating mass compared to steel, and ultra-thin 0.15mm silicon steel stator sheets that minimize eddy current losses. This combination translates directly into cooler running temperatures and extended flight times under high-load conditions.

Rated for 6S LiPo input, the 2750KV windings provide a potent balance of torque and top-end speed, capable of delivering up to 311W of peak power. The robust construction, including high-grade bearings and a precision-machined bell, ensures reliable performance through demanding acrobatic flights and hard impacts, making it a durable choice for advanced pilots.

Key Features

  • Freestyle-Optimized Design: Engineered through six months of testing for optimal power delivery and control response in dynamic flight.
  • Titanium Motor Shaft: Provides superior strength-to-weight ratio, reducing gyroscopic precession and improving durability in crashes.
  • High-Efficiency Stator: 0.15mm silicon steel laminations lower internal resistance (68mOhm) for maximized electrical efficiency and power transfer.
  • High-Thrust Performance: Generates up to 740g of thrust, enabling powerful punch-outs and precise recovery from dives.
  • 6S Voltage Rating: Built to handle the high current (20.1A max) and power demands of modern 6S LiPo batteries.
  • Premium Anodized Finish: Secondary anodizing process enhances surface hardness and provides a consistent, durable color.

Applications

  • 3-inch and 4-inch 6S FPV freestyle quadcopters requiring high power-to-weight ratios.
  • Lightweight 5-inch 6S racing drones where aggressive throttle response is critical.
  • Micro long-range builds utilizing 6S power for efficient high-speed cruising.
  • FPV cinewhoop upgrades seeking more power for dynamic cinematic shots.

Technical Specifications

Motor ModelFS 2204 ELITE
KV Rating2750 KV
Stator Size2204 (22x04mm)
Max Current20.1 A
Max Power311 W
Max Thrust740 g
Internal Resistance68 mOhm
Shaft MaterialTitanium
Voltage Input6S LiPo (22.2V)
Motor TypeOutrunner Brushless

Frequently Asked Questions

What is the compatible propeller size for the MAD Components FS 2204 2750KV motor?

This motor is optimally paired with lightweight 3-inch or 4-inch bi-blade or tri-blade propellers on 6S voltage. For 5-inch props, select very lightweight designs to avoid exceeding the 20.1A max current draw. Always bench-test with a current meter to ensure your prop choice stays within safe limits.

Can the FS 2204 motor handle 4S or 5S LiPo batteries?

Yes, the motor can operate on lower voltages like 4S or 5S, but its performance (RPM and thrust) will be reduced proportionally to the KV rating. It is electrically safe, but the 2750KV winding is specifically tuned to unlock its full potential on 6S power for high-RPM freestyle flight.

What is the benefit of the titanium shaft compared to a steel shaft?

The titanium shaft offers a significantly higher strength-to-weight ratio. This reduces rotational mass, leading to faster throttle response, less gyroscopic effect for crisper handling, and improved durability against bending in crashes compared to standard steel shafts.

What is the mounting hole pattern for this 2204 motor?

The MAD Components FS 2204 motor uses the standard 16x19mm M3 mounting hole pattern common to 22xx-series motors. This makes it compatible with a wide range of 3-inch, 4-inch, and lightweight 5-inch FPV drone frames designed for this mounting standard.

Package Includes

  • 1 x MAD Components Components FS 2204 ELITE FPV Motor (Green) - 2750KV

Additional Information

Weight 0.018 kg
Dimensions 5 × 5 × 4 cm
