MAD Components Components CM 3115 TAURUS FPV Drone Motor 490KV-12S
The MAD Components Components CM 3115 TAURUS is a high-performance 490KV brushless motor engineered for 12S LiPo power systems, delivering up to 1990W of power and 4.8kg of thrust for demanding industrial and cinematic UAV applications.
Features
- Optimized 490KV winding for high-torque, low-RPM operation on 12S LiPo power (44.4V nominal).
- High-power design capable of 41.5A continuous current and 1990W maximum power output.
- Advanced thermal management with internal split exhaust blade rotor for superior heat dissipation.
- Dual ultra-thin stainless steel dust filters integrated into the stator for operation in harsh environments.
- Delivers a maximum thrust of 4.8kg per motor for heavy-lift and professional filming platforms.
Out of stock
The CM 3115 TAURUS motor from MAD Components Components represents a specialized build within the CM Series, targeting the highest levels of dust protection and thermal performance for professional FPV and aerial cinematography drones. Its electrical design, with a 112.5mΩ internal resistance and 490KV rating, is optimized for efficient power conversion on high-voltage 12S battery packs, providing the substantial torque required for lifting heavy camera gimbals and payloads.
Structural durability is central to its design, featuring robust construction to handle the stresses of high-power, long-duration flights. The integrated cooling system, which includes a unique split exhaust blade within the rotor, actively expels heat during operation, maintaining stable performance and extending component lifespan. This motor is engineered for integration into custom heavy-lift multirotor frames where reliability, power, and environmental resilience are non-negotiable.
Additional Information
| Weight | 0.24 kg |
|---|---|
| Dimensions | 10 × 10 × 9 cm |
