Honeywell GPTBG3YG250BSBFX250K Pressure Sensor, 250bar, Stainless Steel Housing, IP69K
The Honeywell GPTBG3YG250BSBFX250K is a high-performance piezoresistive pressure sensor with ASIC signal conditioning, delivering a calibrated analog voltage output for industrial pressure monitoring systems. Housed in durable stainless steel with IP69K protection, it is compatible with 9-30V DC supplies and designed for integration into PLCs, data acquisition systems, and harsh environment machinery.
Features
- Piezoresistive ceramic/thin-film transducer with ASIC signal conditioning for high accuracy.
- Stainless steel housing and IP69K rating for durability in high-pressure washdown environments.
- Wide supply voltage range (9-30V DC) for flexible industrial system integration.
- Calibrated for offset, sensitivity, temperature effects, and non-linearity.
- Rated for over 10 million pressure cycles for long-term reliability.
Out of stock
The Honeywell GPTBG3YG250BSBFX250K pressure sensor employs a piezoresistive sensing element fabricated on a ceramic/thin-film substrate, providing stable and precise measurement of pressures up to 250 bar. An integrated Application-Specific Integrated Circuit (ASIC) provides comprehensive signal conditioning, performing real-time compensation for offset, span, temperature drift, and non-linearity, resulting in a highly accurate analog voltage output.
Encased in a robust stainless steel housing and sealed to IP69K standards, this transducer is engineered to withstand harsh industrial environments, including exposure to high-pressure washdowns, common refrigerants, engine oils, and hydraulic fluids. Its high cycle life and media compatibility make it a reliable component for continuous monitoring in demanding applications.
Additional Information
| Weight | 0.023 kg |
|---|---|
| Dimensions | 10 × 6 × 5 cm |
