Hobbywing X15 Motor+Propeller Combo CCW
The Hobbywing X15 Motor+Propeller Combo CCW is a high-power propulsion system engineered for heavy-lift agricultural drones, delivering 72 kg of thrust per arm and supporting a maximum takeoff weight of 149 kg. It integrates a 300A intelligent ESC with DroneCAN/HWCAN protocol support and is designed for modular installation and maintenance.
Features
- Delivers 72 kg of maximum thrust per motor arm for heavy-lift applications.
- Integrated 300A intelligent ESC with advanced fault protection and DroneCAN/HWCAN communication.
- Features 63-inch carbon-reinforced nylon composite propellers for high efficiency and noise reduction.
- Modular design simplifies installation, tuning, and field maintenance.
- Operates on a wide 69-78.3V DC input range with a 45 KV motor rating.
Out of stock
The Hobbywing X15 Combo is a complete propulsion solution built for demanding commercial UAV operations, particularly in precision agriculture and heavy-lift logistics. Its core is a high-torque 45 KV brushless motor paired with a 300A Electronic Speed Controller featuring real-time monitoring and protection against overcurrent, signal loss, and motor stalls. The system communicates via DroneCAN or proprietary HWCAN protocols, enabling detailed telemetry and parameter adjustment through Hobbywing DataLink or compatible CAN analyzers.
Constructed with a waterproof IPX6-rated bearing and an operating temperature range of -10°C to +40°C, the X15 is built for reliability in varied environmental conditions. The included 63-inch propellers utilize a carbon fiber reinforced nylon composite material, optimizing the blade area for increased thrust efficiency and reduced acoustic signature. This combo is engineered for drones requiring a maximum takeoff weight of up to 149 kg, providing the power and intelligent management needed for extended, stable flight missions.
Additional Information
| Weight | 7.1 kg |
|---|---|
| Dimensions | 78 × 18.5 cm |
