eSUN PLA-CF Purple 1.75mm 3D Filament 1kg

₹2,199.00 (Inclusive of all taxes)
Out of Stock

eSUN PLA-CF filament integrates German-imported carbon fibers into PLA, significantly enhancing strength and modulus. This purple 1.75mm filament delivers a matte, sandblasted texture, ideal for high-speed FDM printing of functional and aesthetic parts.

Features

  • High strength and modulus for durable prints.
  • Distinctive matte finish with carbon fiber texture.
  • Excellent printability, optimized for high-speed FDM.
  • Reinforced properties for structural and aesthetic applications.

Out of stock

Description

The eSUN PLA-CF filament incorporates German-imported organic impregnated short-cut carbon fibers into a PLA base, delivering significantly enhanced strength and modulus compared to standard PLA. This advanced composite material not only boosts mechanical performance but also provides a unique aesthetic, characterized by a matte finish and a distinctive carbon fiber sandblasted texture. It’s engineered for reliability and precision in demanding applications.

Whether your project demands robust structural components or visually striking aesthetic parts, PLA-CF excels with its outstanding attributes. Its exceptional printing performance ensures smooth, consistent extrusion and layer adhesion, making it particularly well-suited for high-speed additive manufacturing without compromising on print quality or part integrity.

Key Features

  • High strength and rigidity from carbon fiber reinforcement.
  • Unique matte appearance with a carbon fiber sandblasted texture.
  • Exceptional printability, compatible with a wide range of FDM printers.
  • Optimized for high-speed 3D printing applications, reducing print times.
  • Improved dimensional stability and reduced warping for precise parts.
  • Suitable for both functional prototypes and aesthetic models.
  • Low odor and easy to print compared to other engineering composites.

Applications

  • Functional prototypes requiring increased rigidity and strength.
  • Jigs, fixtures, and tooling with improved wear resistance.
  • Architectural models and decorative elements where a unique finish is desired.
  • End-use parts for hobbyists and professionals valuing aesthetics and durability.
  • Lightweight, rigid components for RC models or small robotics.

Technical Specifications

Filament Diameter1.75mm
Density1.21 g/cm³
Heat Distortion Temp53.5 °C
Melt Flow Index5.37 g/10min (190°C/2.16kg)
Extruder Temperature190-230 °C
Bed Temperature45-60 °C
Printing Speed50-300 mm/s
Fan Speed100%
Tensile Strength39.3 MPa
Elongation at Break4.27 %
Flexural Strength103.1 MPa
Flexural Modulus5005.9 MPa
Printability Rating9/10
Durability Rating4/10
ColorPurple
Spool Weight1kg

Frequently Asked Questions

What are the optimal printing temperatures for eSUN PLA-CF?

For eSUN PLA-CF, an extruder temperature range of 190-230°C is recommended, with a bed temperature between 45-60°C. These settings ensure good layer adhesion and minimize warping, crucial for achieving strong, dimensionally accurate parts with a quality surface finish during high-speed printing.

Does eSUN PLA-CF require special nozzle considerations due to carbon fiber?

Yes, due to the abrasive nature of carbon fibers, it is highly recommended to use a hardened steel or wear-resistant nozzle with eSUN PLA-CF. Standard brass nozzles will wear down quickly, leading to inconsistent extrusion and print quality issues over time. This ensures longevity and consistent performance.

How does the carbon fiber content enhance PLA's properties in eSUN PLA-CF?

The German-imported organic impregnated short-cut carbon fibers significantly enhance PLA's mechanical properties, increasing tensile and flexural strength, as well as modulus. This reinforcement results in stiffer, more durable prints with improved dimensional stability compared to standard PLA, while also imparting a distinctive matte, sandblasted texture.

Is eSUN PLA-CF suitable for high-speed 3D printing?

Absolutely. eSUN PLA-CF filament is specifically engineered for exceptional printing performance, making it highly suitable for high-speed 3D printing applications. Its consistent diameter and optimized material flow contribute to reliable extrusion at speeds ranging from 50 to 300 mm/s, enabling faster production cycles without compromising print quality.

Package Includes

  • 1x eSUN PLA-CF Purple 1.75mm 3D Printing Filament Spool (1kg)

Additional Information

Weight 1.3 kg
Dimensions 20 × 22 × 7 cm
