DYS D3536-5 1450KV Brushless Motor
The DYS D3536-5 is a 1450KV brushless outrunner motor engineered for multirotor and fixed-wing UAV applications, compatible with 2-4S LiPo batteries (7.4-14.8V). It delivers up to 655W of power and 1380g of thrust, featuring pre-soldered 3mm bullet connectors for direct ESC integration.
Features
- 1450KV outrunner motor optimized for 2-4S LiPo (7.4-14.8V) operation.
- Delivers up to 655W max power and 1380g of maximum thrust.
- Includes pre-soldered 3mm bullet connectors for plug-and-play ESC compatibility.
- 12-pole N52SH neodymium magnet design for smooth, efficient torque.
- 5mm hardened steel shaft and robust housing for durable, long-term use.
Out of stock
The DYS D3536-5 brushless motor is a high-torque outrunner designed for demanding UAV platforms, including heavy-lift quadcopters and endurance-focused fixed-wing aircraft. Its 1450KV rating and 12-pole stator configuration provide a balanced blend of rotational speed and low-end torque, making it suitable for larger propellers like 9×6″ on 3S or 8×4″ on 4S setups.
Constructed with a precision-machined aluminum housing and a 5mm hardened steel shaft, the motor is built to withstand the vibrations and thermal stresses of prolonged flight. The low internal resistance of 0.023 ohms contributes to its high electrical efficiency, reducing heat buildup and extending flight times. Pre-installed 3mm bullet connectors simplify wiring and ensure reliable connections to compatible 30-50A ESCs.
Additional Information
| Weight | 0.135 kg |
|---|---|
| Dimensions | 8 × 5 × 5 cm |
