Dwyer Instruments RHPX-2LHAB-00 Humidity & Temperature Transmitter, 0-100% RH, 10kohm Type II Thermistor, Wall Mount, Large IP66 Enclosure
The Dwyer Instruments RHPX-2LHAB-00 is a high-accuracy wall-mount transmitter for reliable indoor humidity and temperature monitoring, featuring selectable 4–20mA, 0–5V, or 0–10V analogue outputs for seamless integration into HVAC, BMS, and industrial control systems.
Features
- High-accuracy humidity sensing with 0–100% RH range and ±2% performance.
- Integrated passive 10 kΩ Type II thermistor for -40°C to 60°C temperature monitoring.
- Selectable analogue output: 4–20mA, 0–5V, or 0–10V for flexible system integration.
- Large IP66-rated enclosure with factory-installed HDPE filter and solar radiation shield.
- Tool-free, wall-mount design for simplified installation and maintenance.
Out of stock
The Dwyer Instruments RHPX-2LHAB-00 Humidity and Temperature Transmitter is engineered for precision environmental monitoring in critical indoor applications. It utilizes a high-stability capacitive polymer sensor for humidity and a passive 10 kΩ Type II thermistor for temperature, delivering reliable data for building energy management and HVAC control.
Housed in a large, robust IP66 enclosure, the transmitter is protected against dust and water jets. The inclusion of a factory-installed HDPE filter and a solar radiation shield ensures long-term measurement stability by minimizing contamination and thermal radiation effects. Its selectable analogue output (4–20mA/0–5V/0–10V) and 10–35 VDC power input provide versatile compatibility with PLCs, DDCs, and data acquisition systems.
Additional Information
| Weight | 1.248 kg |
|---|---|
| Dimensions | 26.72 × 14.566 × 13 cm |
