BIGTREETECH TMC2225 V1.0 Stepper Motor Driver
BIGTREETECH TMC2225 V1.0 Stepper Motor Driver - Image 2
BIGTREETECH TMC2225 V1.0 Stepper Motor Driver - Image 3
SKU: 3DDF-1831
📋 GST Invoice Available

BIGTREETECH TMC2225 V1.0 Stepper Motor Driver

₹399.00 (Inclusive of all taxes)
Out of Stock

This BIGTREETECH TMC2225 V1.0 Stepper Motor Driver offers ultra-silent and precise control for 2-phase stepper motors. Featuring advanced StealthChop2 and SpreadCycle technology, it ensures exceptionally smooth operation and high compatibility with popular 3D printer mainboards.

Features

  • Achieve ultra-silent motor operation with StealthChop2 technology.
  • Experience smooth motion with 256 microsteps via MicroPlyer interpolation.
  • Benefit from highly dynamic motor control using the SpreadCycle chopper.
  • Supports both STEP/DIR interface and Single Wire UART for flexible configuration.
  • Integrated power-MOSFETs handle up to 1.4A RMS motor current.

Out of stock

Description

The BIGTREETECH TMC2225 V1.0 is an advanced, ultra-silent motor driver IC designed for precise control of two-phase stepper motors. Its intelligent design incorporates TRINAMIC’s sophisticated StealthChop2 chopper, which delivers virtually noiseless operation, maximized efficiency, and optimal motor torque, significantly enhancing the printing experience by reducing operational noise.

This driver features fast current regulation and an optional combination with SpreadCycle, enabling highly dynamic motion for rapid and accurate movements in 3D printing applications. With integrated power-MOSFETs capable of handling motor currents up to 1.4A RMS, the TMC2225 provides robust and reliable performance. Protection and diagnostic features ensure stable, long-term operation, while a user-friendly UART interface unlocks further tuning and control options, allowing application-specific settings to be stored in OTP memory for personalized optimization.

Key Features

  • Excellent heat dissipation for sustained performance.
  • Ultra-quiet operating volume for minimal noise pollution.
  • Ensures precise operation for high-quality prints.
  • Improved overall performance compared to legacy drivers.
  • High compatibility with various 3D printer mainboards.
  • Delivers smooth motor steps, reducing layer artifacts.
  • Integrated protection and diagnostic features for robust use.
  • Supports standalone motion via integrated pulse generator.

Applications

  • Upgrade or replacement in popular FDM 3D printers (e.g., Creality Ender 3/5, CR-10 series).
  • Integration with BIGTREETECH SKR series and other compatible control boards for enhanced performance.
  • General 2-phase stepper motor control applications requiring silent, precise, and dynamic operation.
  • Custom 3D printer builds and CNC projects demanding advanced motor control features.

Technical Specifications

Item TypeStepper Motor Driver, BTT Motor Driver
Voltage Rating (V)4.75 to 36
Current Rating (A)2 (Peak)
Peak Current (A)2
Microstep256
Operation ModeUART/STEP&DIR
Compatible ModelsCreality 3D CR-10S, CR-10S Pro, Ender 3, Ender 3 Pro, Ender 3 V2, Ender 3 MAX, Ender 5, SKR 2 Control Board, Creality 3D CR-10

Frequently Asked Questions

What 3D printer mainboards are compatible with the TMC2225 V1.0 driver?

The TMC2225 V1.0 offers broad compatibility with many 3D printer mainboards. Specifically, it works well with Creality CR-10 series, Ender 3/5 series, and BIGTREETECH SKR 2 control boards. Its standard pinning allows for straightforward integration into most systems designed for common stepper drivers, enhancing versatility for upgrades.

How does StealthChop2 technology improve 3D printing performance?

StealthChop2 significantly reduces motor noise by optimizing current control, leading to ultra-silent operation during printing. This technology also ensures smoother motor movements, which can translate into improved print quality with fewer visible layer lines and artifacts, especially at lower speeds, making for a quieter and more precise printing experience.

What is the function of MicroPlyer interpolation in this driver?

MicroPlyer interpolation enhances microstep resolution, allowing the TMC2225 V1.0 to achieve 256 microsteps from lower resolution STEP/DIR inputs. This effectively smooths out the motor's rotation, reducing vibrations and improving positional accuracy. The result is a more fluid motion profile, contributing to finer details and a better surface finish on 3D printed objects.

Can the TMC2225 V1.0 be configured via UART, and what are the benefits?

Yes, the TMC2225 V1.0 supports single-wire UART communication. This allows advanced configuration options, such as dynamic current control, chopper settings, and diagnostic feedback, to be adjusted via firmware. UART configuration offers greater flexibility and fine-tuning capabilities compared to traditional STEP/DIR drivers, optimizing performance for specific motors and applications.

Package Includes

  • 1 x BIGTREETECH TMC2225 V1.0 Stepper Motor Driver
  • 1 x Heatsink
  • 1 x 1-pin Connector Cable

Additional Information

Weight 0.003 kg
Dimensions 2 × 1.5 × 1.5 cm
