BigTreeTech BigTreeTech ESP-07S Wi-Fi Module for SKR Octopus & SKR 2
The BigTreeTech BigTreeTech ESP-07S is a dedicated Wi-Fi module designed for direct integration with SKR Octopus and SKR 2 3D printer control boards. It enables wireless printer control via ESP3D with Marlin firmware or Duet Web Control (DWC) with RepRap Firmware, operating on 2.4GHz Wi-Fi.
Features
- Direct plug-in compatibility with BigTreeTech SKR Octopus V1.1 and SKR 2 motherboards for seamless 3D printer wireless control.
- Enables remote management via ESP3D web interface for Marlin or Duet Web Control (DWC) for RepRap Firmware.
- Powered by a 32-bit microcontroller supporting 80 MHz and 160 MHz clock speeds with RTOS capability.
- Features 2.4GHz Wi-Fi (2400-2483.5MHz) with WEP/WPA-PSK/WPA2-PSK security and up to 100m transmission range.
- Provides versatile interfaces including UART, GPIO, ADC, and PWM for expanded control and sensor integration.
Out of stock
The BigTreeTech BigTreeTech ESP-07S Module is a purpose-built wireless communication solution engineered for the 3D printing ecosystem. It leverages a robust ESP8266-based core, offering dual clock speeds of 80 MHz and 160 MHz, to handle network tasks and peripheral communication efficiently. The module connects directly to the designated headers on compatible BigTreeTech mainboards, eliminating the need for complex wiring.
Its primary function is to bridge the 3D printer’s control board to a local network, allowing for remote monitoring, file transfer, and real-time control via a web browser. The module supports standard UART communication at configurable baud rates from 300 to 4,608,000 bps, defaulting to 115200 bps for reliable data exchange with the host microcontroller. With a compact form factor and a 3.0V to 3.6V power supply requirement drawing over 500mA, it’s designed for embedded operation within printer enclosures.
Additional Information
| Weight | 0.005 kg |
|---|---|
| Dimensions | 2.2 × 2 × 1.3 cm |
