AxisFlying C145 1404.5 Brushless Motor 4500KV - Standard

Name: AxisFlying C145 1404.5 Brushless Motor 4500KV - Standard
Brand: AxisFlying
SKU: DRFC-2428
Price: 2109.00 INR
Availability: OutOfStock

₹2,109.00 (Inclusive of all taxes)

Out of Stock

The AxisFlying C145 1404.5 brushless motor is a 4500KV unit engineered for 2.5-inch cinewhoop and cinematic drone builds, optimized for 3S LiPo battery systems to deliver responsive thrust and smooth power delivery for stable aerial filming.

Features

4500KV rating optimized for 3S (11.1V) LiPo operation.
14×4.5mm stator size provides a high power-to-weight ratio for 2.5-inch propellers.
Lightweight 20g design enhances flight agility and overall drone efficiency.
3mm shaft diameter with 9x9mm mounting pattern for broad frame compatibility.
Robust construction supports continuous current handling up to 30A.

Out of stock

Get Notified When Available

Description

The AxisFlying C145 1450.5 motor is engineered for compact, high-performance drone applications. Its 14mm stator diameter and 4.5mm height create a balanced electromagnetic core, delivering efficient torque and RPM for 2.5-inch propeller setups. The design prioritizes a minimal weight footprint to preserve the agile flight characteristics essential for cinematic FPV and tight-space cinewhoop maneuvers.

Built with high-grade materials, the motor features an optimized thermal management system to dissipate heat effectively, supporting sustained performance during extended flight sessions. The 3mm hardened steel shaft and standardized 9x9mm mounting holes ensure secure installation and compatibility with a wide range of lightweight frames and durable propellers.

Key Features

Precision-Wound Stator: High-precision windings maximize electromagnetic efficiency for consistent power output and smooth throttle response.
Enhanced Cooling Design: Optimized internal airflow and external finning reduce operating temperatures, enabling longer flight durations.
Durable Mechanical Construction: Utilizes reinforced bearings and a robust bell housing to withstand the vibrations and impacts of aggressive flying.
Optimized Weight Distribution: The 20g mass is strategically balanced to minimize gyroscopic effects and improve overall flight stability.
High-Current Capability: Engineered to handle peak currents, ensuring reliable performance during rapid acceleration and high-thrust maneuvers.

Applications

2.5-inch Cinewhoop builds for indoor and proximity cinematic filming.
Compact cinematic FPV drones requiring smooth and responsive throttle control.
Lightweight freestyle or racing quadcopters in the 2.5-inch to 3-inch size class.
Micro long-range or exploration builds where efficiency and weight are critical.

Technical Specifications

Model	AxisFlying C145 1404.5
KV Rating	4500 KV
Stator Size	14mm x 4.5mm (1404.5)
Input Voltage	Optimized for 3S LiPo (11.1V)
Max Continuous Current	30A
Shaft Diameter	3mm
Mounting Pattern	9x9mm
Weight	20g
Recommended Prop Size	2.5-inch

Frequently Asked Questions

What is the recommended battery voltage for this AxisFlying C145 motor?

The AxisFlying C145 1404.5 motor is optimized for 3S LiPo battery systems (nominal 11.1V). Operating within this voltage range ensures optimal performance, efficiency, and motor longevity. Exceeding this voltage is not recommended.

What size propellers are compatible with this 4500KV motor?

This motor is designed and performs best with 2.5-inch propellers. The 4500KV rating and stator size provide the ideal torque and RPM balance for this propeller class, making it suitable for cinewhoop and lightweight cinematic drone builds.

What is the mounting pattern and shaft diameter?

The motor features a standard 9x9mm mounting hole pattern and a 3mm diameter shaft. This is a common configuration compatible with a wide variety of micro and cinewhoop frames, as well as corresponding propeller hubs and adapters.
