Arduino CNC Shield V4 3-Axis Stepper Motor Driver
The CNC Shield V4 is a compact expansion board designed for the Arduino Nano, enabling control of up to three 2-phase 4-wire stepper motors. It facilitates development for micro-drive laser engraving machines and 3-axis CNC engraving applications with GRBL compatibility.
Features
- Designed for seamless integration with Arduino Nano boards.
- Supports control of up to three 2-phase 4-wire stepper motors with 2A capacity per axis.
- Features exposed digital I/O for endstops and an I2C interface for LCDs or other modules.
- Fully compatible with GRBL firmware for open-source CNC machine control.
Out of stock
The CNC Shield V4 is specifically engineered to interface with the Arduino Nano, providing a robust and efficient platform for motor control in compact CNC and 3D printer applications. This expansion board simplifies the wiring and control logic by requiring only two digital I/O pins per stepper motor channel, making it possible to manage three independent stepper motors with a total of six I/O lines.
Its design focuses on ease of use and expandability, offering dedicated headers for stepper motor drivers and convenient access to digital I/O pins for limit switches (endstops) and other sensors. Furthermore, an exposed I2C interface allows for straightforward connection of external modules like LCD displays, enhancing user interaction and data visualization for your embedded projects.
Additional Information
| Weight | 0.032 kg |
|---|---|
| Dimensions | 7.3 × 5.9 cm |
