A4988/DRV8825 Stepper Driver Expansion Board for 3D Printers

This expansion board is designed to extend the interface and functionality of A4988 or DRV8825 stepper motor driver modules. It enables advanced control over stepper motors in 3D printers, providing critical connections for direction, enable, and speed signals, thereby improving printing precision and performance.

The board supports a reasonable DC voltage of 5 volts for its internal logic. For the stepper motor power supply, it accepts an input voltage ranging from 12 to 24 volts. This flexibility accommodates various 3D printer power configurations, ensuring broad compatibility.

The expansion board allows for precise configuration of micro-stepping through integrated jumper settings. It supports 16 subdivisions for A4988 drivers and 32 subdivisions for DRV8825 drivers. This functionality provides smoother motor movement and higher resolution prints.

The board incorporates several safety features crucial for reliable operation. These include a thermal extinguishing circuit to prevent overheating, robust ground connection protection against electrical faults, and short circuit protection. These elements safeguard both the board and the connected driver modules.

While the listing mentions "good for MKS GEN," this expansion board is generally compatible with any 3D printer mainboard that utilizes A4988 or DRV8825 stepper motor drivers. It provides the necessary interface to upgrade or replace existing driver setups, offering enhanced control and protection.
