Realtek RTL8762E BLE 5.2 Module Commercial Grade
The USE 8762E BLE Module is a commercial-grade, ultra-low-power system-on-chip (SoC) supporting Bluetooth 5.2 Low Energy and 2.4GHz proprietary protocols, built around an ARM Cortex-M0+ core for embedded IoT applications.
Features
- Bluetooth 5.2 LE certified with support for 2Mbps PHY, LE Long Range, and Advertising Extensions for enhanced data rate and coverage.
- Ultra-low power architecture with intelligent PMU and multiple low-energy states, ideal for battery-operated IoT devices.
- Integrated ARM Cortex-M0+ MCU with 272KB ROM and 104KB SRAM to execute the protocol stack and application firmware.
- High-performance RF transceiver with -97dBm receiver sensitivity and +7.5dBm transmit power for robust wireless links.
- Multi-protocol support for concurrent BLE and 2.4GHz proprietary applications, plus integrated analog MIC interface for voice commands.
Out of stock
The USE 8762E BLE Module is a fully integrated, commercial-grade wireless SoC designed for demanding Bluetooth Low Energy 5.2 applications. It combines a high-performance 2.4GHz RF transceiver with an energy-efficient ARM Cortex-M0+ microcontroller, power management unit, and a rich set of peripherals including an ADC, hardware key scanner, and IR transceiver on a single QFN package.
Engineered for ultra-low power consumption, the module features intelligent power management supporting multiple deep sleep states, making it suitable for always-on, battery-powered sensor nodes, beacons, and remote controls. Its robust RF performance, with -97dBm sensitivity and configurable output power up to +7.5dBm, ensures reliable communication in diverse environments.
Beyond standard BLE, the RTL8762E chipset supports 2.4GHz proprietary protocols, allowing developers to implement custom wireless stacks. The integrated analog microphone interface with sigma-delta ADC and programmable gain amplifier further extends its utility to voice-activated IoT devices, enabling local voice command processing without external components.
Additional Information
| Weight | 0.01 kg |
|---|---|
| Dimensions | 5 × 6 × 2 cm |
