DFRobot SEN0314 MU Vision Sensor ESP32 AI Camera
The DFRobot SEN0314 MU Vision Sensor is an ESP32-powered AI camera module delivering local, on-device vision processing for robotics and STEM applications. It supports Arduino, MicroPython, and Micro:bit platforms via UART, I2C, or Wi-Fi interfaces, operating from 3.3V to 5V DC.
Features
- ESP32 dual-core 240MHz processor handles all vision algorithms locally, ensuring privacy and offline operation.
- 640×480 pixel resolution with an 85° FOV for color, ball, human, and card/shape recognition tasks.
- Multi-interface flexibility with UART, I2C, and Wi-Fi connectivity for seamless integration into Arduino, Micro:bit, and other embedded systems.
- Wide 3.3V to 5V operating voltage range allows direct powering from most development boards and microcontroller platforms.
- Compact 80x60mm footprint with low power consumption, ideal for mobile robotics and educational AI vision projects.
Out of stock
The DFRobot SEN0314 MU Vision Sensor integrates an ESP32 dual-core processor to perform real-time computer vision tasks entirely on-device, eliminating the need for cloud connectivity or external networks. This local processing architecture not only safeguards data privacy but also enables rapid response times for robotics applications such as object tracking, color detection, and human presence sensing.
Designed for educational and prototyping environments, the sensor provides multiple communication pathways including a serial UART for direct command control, I2C for bus-based systems, and built-in Wi-Fi for wireless data streaming or remote configuration. Its low-power design and wide input voltage compatibility make it suitable for battery-operated projects, while the included PH2.0 adapter cable simplifies wiring to common microcontroller pinouts.
Additional Information
| Weight | 0.15 kg |
|---|---|
| Dimensions | 8 × 6 cm |
